Solid Body tweeter
Milled from a solid block of aluminium, the solid body tweeter housing design creates an acoustically optimised housing for the tweeter – one that’s exceptionally inert and resistant to resonances.
Carbon Dome™ tweeter
Carbon Dome tweeters are a brand new technology purpose-built for the 700 Series. Delivering a dramatic improvement on the aluminium double-dome tweeter, they raise the breakup threshold to 47kHz, for pinpoint imaging accuracy and detail.
First introduced with the 800 Series Diamond, the Continuum cone represents the biggest step-change in midrange performance since Kevlar. Its woven, coated material provides highly controlled break-up, resulting in a more open, neutral midrange.
The midrange driver in the floor-standers feature a decoupled design, adapted from a similar system in the 800 Series Diamond. Decoupling reduces cabinet colouration, and boosts midrange clarity.
Technical features: Decoupled Carbon Dome tweeter
Solid Body Tweeter on top
Continuum cone FST midrange
Aerofoil profile bass cones
Description: 3-way vented-box system
Drive units: 1x ø25mm (1 in) Decoupled Carbon Dome high-frequency1x ø150mm (6 in) Continuum cone FST midrange3x ø165mm (6.5 in) Aerofoil profile bass
Frequency range: -6dB at 28Hz and 33kHz
Frequency response: 45Hz – 28kHz ±3dB
Sensitivity: 90dB spl (2.83Vrms, 1m)
Harmonic distortion: 2nd and 3rd harmonics (90dB, 1m)
<1% 86Hz - 28kHz <0.5% 110Hz - 20kHz Nominal impedance: 8Ω (minimum 3.1Ω)
Recommended amplifier power: 30W – 300W into 8Ω on unclipped programme
Dimensions: Height: 994mm (39 in) cabinet only
1087mm (42.8 in) including tweeter and plinth
Width: 200mm (7.9 in) cabinet only
366mm (14.4 in) including plinth
Depth: 337mm (13.3 in) cabinet only
364mm (14.3 in) inc. grille and terminals
Net weight: 29.5kg (65 lb)
Finishes: Cabinet: Rosenut
Grey (Satin White only)
