Product Description
Marantz doesn’t believe that home cinema performance should come at the expense of music playback, and the SR7012 is designed to sit at the heart of a complete high-end home entertainment system, with nine powerful amp channels built-in. It has a wide range of facilities to enable your favourite music to be shared and enjoyed, including network streaming, compatibility with ultra-high-resolution music formats, Bluetooth and Airplay for playback from portable devices, and the HEOS wireless multiroom system.
Key Features
-
- 9.2 channel AV Receiver with 200 W per channel
- 4K/60 Hz full-rate pass-through, 4:4:4 color resolution, HDR, BT.2020 , Dolby Vision and HLG (Hybrid Log Gamma) pass-through
- 8 HDMI inputs (incl. 1 front) with full HDCP 2.2 support; 3 HDMI outputs (incl. Zone 2)
- eARC (Enhanced Audio Return Channel) support via firmware update
- Analogue to HDMI conversion and SD to HD/4K Upscaling
- Dolby Atmos (up to 7.1.4 with an external 2ch amplifier), DTS:X™, and Auro-3D built-in
- DTS Virtual:X™ (via free-of-charge firmware update in 2018) > Enjoy the complete immersive experience regardless the number of speakers installed
- Built-in Wi-Fi with 2.4GHz/5GHz dual band support
- Built-in HEOS Wireless Multi-Room Audio Technology
- AirPlay, Bluetooth, Internet Radio, Spotify Connect, TIDAL, Deezer and more
- DSD (2.8/5.6MHz), FLAC, ALAC and WAV support
- Audyssey MultEQ XT32, LFC, Sub EQ HT, Dynamic Volume and Dynamic EQ
- Colour-coded speaker terminals, Setup Assistant, Marantz 2016 AVR Remote App
- Intelligent ECO mode with off/on/auto setting
- Advanced multiroom options; 11.2-channel processing with pre-outs for all channels; RS232Control; Crestron Connected
SPECIFICATIONS
Multichannel Surround
DTS HD Master / DTS:X o / o
DTS Neo:X / DTS Neural:X – / o
Dolby TrueHD / Dolby Atmos o / o
Dolby ProLogic Il / Dolby Surround – / o
Auro 3D o
Multichannel Stereo o
max. number of processing (preamp) channels 11.2
Sound Enhancements
Single Board Power Amplifier –
Discrete Power Amplifier 9
Copper plated chassis –
Power Transformer: Toroidal / EI EI
Current Feedback Topology o
Hyper Dynamic Amplifier Modules (HDAM) o
Pure Direct o
High Grade Audio Components o
Gold plated RCA terminals o
Clock Jitter Reducer o
Audyssey MultEQ XT32
Audyssey Dynamic EQ / Dynamic Volume o / o
Audyssey LFC o
Audyssey APP support o
Compressed audio Enhancer: MDAX2 o
Network
HEOS Multiroom & Streaming o
Lossy formats MP3 / WMA / AAC o / o / o
Lossless formats FLAC / ALAC / WAV o / o / o
Lossless formats: FLAC HD 192/24 / WAV 192/24 / ALAC 192/24 o / o / o
DSD Audio Streaming up to DSD5.6
FLAC HD 192/24 o
WAV 192/24 o
ALAC 192/24 o
Gapless playback o (FLAC, WAV, ALAC, DSD)
AirPlay audio streaming o
Internet Radio TuneIn
Spotify Connect* / Tidal* / Deezer* / others * o / o / o / o
Compatible with Remote APP for Smart Phones Android / iOS
Compatible with Remote APP for Tablets Android / iOS/Amazon Kindle
Ethernet o
WiFi o
Bluetooth o
HDMI
HDMI inputs back / front 7 / 1
HDCP2.2 support o
HDMI outputs main / zone 2 / 1
Video conversion Analog -> HDMI o
Analogue to HDMI scaling 480i/576i up to 4K 60/50
HDMI to HDMI scaling up to 4K 60/50
GUI Overlay on HDMI o
HDMI: 3D / 4K / CEC / ARC o / o / o / o
Enhanced ARC o
Dolby Vision / HLG o / o
4k signal pass-through / scaling / GUI overlay o / o / o
HDMI pass-though in standby mode o
Picture adjust / Noise reduction o / o
CEC o
DSD Audio capability o
Audio Return Channel o
Auto LipSync o
MULTIROOM / CI
HEOS Multiroom integrated o
TV Sound grouping o
Multiroom zones 2
Zone audio source: HDMI / opt, coax / Network, USB / analog o (2ch) / o (2ch) / o / o
Zone audio output: speaker / preout o / o
Zone HDMI output from HDMI source o
IP control / RS232 control / Web control / App control o / o / – / o
IR Flasher In o
Marantz remote bus o
DC Trigger output 1
Others
Auto speaker setup by microphone Audyssey MultEQ XT32
FL Display port hole
Graphic User Interface – GUI Advanced
ISF certification o
GUI languages 9
Setup Assistent o
Smart Select o
Firmware Update by Network / USB o / o
Variable cross over o
Optimized Bass Redirection o
Bass Sync –
ECO Mode o
Auto Power off o
Sleep Timer o
Inputs/Outputs
Composite In / Out 3+1 / 1
Component In / Out 2 / 1
HDMI In / Out 7+1 / 2
Multi-Room Video Out: Video / HDMI – / o
Analogue In / Out 5+1 / –
Phono (MM) In o
Digital Inputs: Coaxial / Optical 2 / 2
Multi-Room Out: analog / digital 1 / –
Multichannel Pre Out o (11.2)
Subwoofer Out 2 (independant)
7.1 multichannel input o
Speaker Terminal: Gold plated screw / regular screw o / –
Number of speaker terminals 11
Speaker A/B / Bi-amp drive / Multi-Room Speaker assignable
Speaker A / B assignable
Bi-amp drive assignable
Multi-Room Speaker Terminal assignable
Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB o / o / – / o / o
USB Audio / Made for iPod / Works with iPhone o / AirPlay / AirPlay
FM Tuner with RDS o
Specifications
number of poweramps 9
Power Output (8 ohm, 20 Hz – 20 kHz, 0.08% 2ch Drive) 125 W
Power Output (8 ohm, 20 Hz – 20 kHz, 0.05% 2ch Drive) –
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive) 165 W
Power Output (6 ohm, 1 kHz, 1% 1ch Drive) 200 W
70% Guarantee o
General
Metal Front Panel: o
System Remote Control: RC035SR
Pre-programmed / Learnable / LCD Display – / – / –
Power Consumption in W: 710
Power consumption No-Sound (ECO on / off) in W: 65 W / 110 W
Standby Consumption in W: 0.2
CEC Standby Consumption in W: 0.5
Network Control On Consumption in W: 3.7
Maximum Dimensions
Antenna:Horizontal:(W x D x H) in mm: 440 x 411 x 185
Antenna:Vertical :(W x D x H) in mm): 440 x 411 x 247
w/o Antenna :(W x D x H) in mm: 440 x 401 x 185
Weight in kg: 14.2
