Bowers & Wilkins PV1D Subwoofer


Bowers & Wilkins

For full details please contact the store or go to Bowers & Wilkins Diamond Rewards


SKU: pv1d Categories: ,


Contact store for details.

Technical features Paper-Kevlar®/aluminium composite diaphragm drivers, Balanced drive, Digital Signal Processing, 400W Class-D amplifier

Description Active, balanced-drive closed-box subwoofer system
Drive units 2x 200mm (8in) Paper-Kevlar®/aluminium cone long-throw
Frequency range* -6dB at 6.5Hz and 570Hz
Frequency response* 7.5Hz – 450Hz ±3dB on reference axis
Amplifier Power output: 400W, Rated power consumption: 150W, Standby power consumption: <1W
Input impedance: 100kΩ, Signal/noise: >100dB
Functions  5 presets, Input sensitivity (analogue), Gain (digital), Low-pass filter: frequency, slope, phase, Auto on/standby, 12V trigger on/standby, 12V trigger preset switching, RS-232 automation control
Inputs Stereo line in (2x RCA/Phono/Cinch), Speaker level in (5m cable supplied)
Dimensions Height: 342mm (13.5in), Width: 270mm (10.6in), Depth: 358mm (14.1in)
Net weight 18.7kg (41lb)
Finishes Matte Black or Matte White



Retaining the balanced drive and pressure vessel concept of its predecessor, PV1D sports a fresh new design and a version of the DSP platform developed for the acclaimed DB1. Digital processing provides greater control and versatility, allowing PV1D to integrate seamlessly with a wide variety of satellite speakers, either to create truly impressive home theatre systems, or to simply extend their bass response for two-channel applications. There is power on tap to fully reproduce the most demanding special effects in movies, but PV1D retains all the musical nuances for which its predecessor was renowned.

Additional information


Matte Black, Matte White
