Marantz SR5013 7.2 Channel Full 4K Ultra HD Network AV Surround Receiver with HEOS and Alexa voice

Description

The amplifier section is rated at 180 watts on each of its seven channels, giving it the power to fill even large spaces, while advanced Audyssey MultEQ XT tailors its sound perfectly to your room. For vinyl lovers the SR5013 comes equipped with a direct phono input.
The video section features 8 HDMI inputs (including 1 on the front panel), with full compatibility with the latest 4K Ultra HD video specification, including 60 Hz full rate content, 4:4:4 Pure Color sub-sampling, BT.2020, HDR, HLG (Hybrid Log Gamma) and Dolby Vision compatibility. It’s also HDCP 2.2 compliant, for 4K Ultra HD copy-protected content.
Built-in HEOS wireless multi-room music network technology means the SR5013 can become the hub of a HEOS system, letting you enjoy your favourite music around your home. Explore, browse, and play music from your own network library, from online streaming services, and from thousands of internet radio stations – all controlled using the free HEOS app or by voice in combination with an Amazon Echo device. The SR5013 also features Bluetooth and AirPlay 2 compatibility to stream music directly from any compatible device.

Key Features

• • • • • • • 7.2 channel AV Receiver with 180 watts per channel
            • Enough power to fill bigger rooms with renowned Marantz sound
            • 4K/60 Hz full-rate pass-through, 4:4:4 color resolution, HDR, BT.2020 and Dolby Vision
            • Latest HDMI standard for future-proof compatibility
            • 8 HDMI inputs (incl. 1 front) with full HDCP 2.2 support; 2 HDMI outputs
            • Extended connectivity: ready to feed a TV and projector in parallel
            • Analogue to HDMI conversion and SD/HD to HD/4K Upscaling
            • HD video quality from existing DVDs or analogue sources
            • Dolby Atmos (up to 5.1.2) and DTS:X™ (from 2.1.2 up to 5.1.2)
            • Immersive 3D sound with effects from overhead
            • DTS Virtual:X™
            • Enjoy the complete immersive experience without overhead speakers installed
            • Marantz HDAM (Hyper Dynamic Amplifier Module)
            • Marantz proprietary amplifier technology revealing any audio detail
            • Built-in Wi-Fi with 2.4GHz/5GHz dual band support
              stable Wi-Fi network connection especially in crowded environments
            • Built-in HEOS Wireless Multi-Room Audio Technology
            • AirPlay 2, Bluetooth, Internet Radio, Spotify Connect, Napster, Amazon Music, TIDAL, Deezer and more
            • Access to almost unlimited online music sources
            • Advanced reference-class 32-bit AKM D/A converters on all channels.
            • DSD (2.8/5.6MHz), FLAC, ALAC and WAV support
            • High Resolution audio streaming, even gapless
            • Audyssey MultEQ XT, Dynamic Volume and Dynamic EQ
            • Delivering perfect equalization for your individual room
            • Works With Amazon Alexa
            • Controlling the unit and selecting music by voice (Amazon Echo device required)
            • Color-coded speaker terminals, Setup Assistant, Marantz AVR Remote App
            • Hassle-free installation, setup and operation
            • Intelligent ECO mode with off/on/auto setting
            • Energy-conscious without compromising on performance
            • Advanced Multi-Room options; 7.2ch Pre-out; RS232 Control
            • Audio and video in multiple rooms; ready for 3rd Party Home Automation systems
            • Now available – Apple AirPlay 2

          FEATURES SR5013
          MULTICHANNEL SURROUND
          DTS HD Master / DTS:X / DTS Neural:X • / • / •
          DTS Virtual:X •
          Dolby TrueHD / Dolby Atmos / Dolby Surround • / • / •
          Auro-3D / Auromatic – / –
          Multichannel stereo •
          Max number of processing (Preamp) channels 7.1
          Audyssey MultEQ XT
          Audyssey Dynamic EQ / Dynamic Volume • / •
          Compressed audio enhancer: MDAX2 •
          NETWORK
          HEOS Multi-room streaming / network audio streaming • / •
          Lossy formats: MP3 / WMA / AAC • / • / •
          Lossless formats: FLAC / ALAC / WAV • / • / •
          FLAC HD 192/24 / WAV 192/24 / ALAC 192/24 • / • / •
          DSD audio streaming up to DSD5.6
          Gapless playback • (FLAC, WAV, ALAC,
          DSD)
          AirPlay audio streaming • (AirPlay2 via FW
          update)
          Internet Radio (TuneIn) • (TuneIn)
          Spotify connect / Deezer / TIDAL / Napster / Pandora / SiriusXM • / • / • / • / • / •
          Compatible with Remote app (iOS/Android) Marantz 2016 AVR
          Remote
          Ethernet / Wi-Fi • / • (dual antenna/
          dual band)
          Bluetooth •
          HDMI
          4K 60Hz 4:4:4 resolution / HDCP 2.2 • / •
          eARC (Enhanced Audio Return Channel) –
          Analog to HDMI scaling 480i/576i up to 4K
          30/25/24
          HDMI to HDMI scaling up to 4K 30/25/24
          GUI overlay on HDMI •
          HDR / HLG / Dolby Vision • (HDR10) / • / •
          3D signal pass-through •
          HDMI pass-through in Standby Mode •
          MULTIROOM / CI
          HEOS multi-room integrated •
          HEOS Link compatibility: IR/ IP • / •
          Multi-room zones 2
          Zone audio source: HDMI / Opt, Coax / Network, USB / Analog – / – / • / •
          IP Control / RS232 Control / Web Control / App Control • / • /• / •
          Domotz Pro / IHIJI • / •
          INPUTS/OUTPUTS
          VIDEO
          Composite in/out 2+1 / 1
          Component in/out 2 / 1
          HDMI in/out 7+1 / 2
          AUDIO
          Analog In / Out 4+1 / –
          Phono (MM) in •
          Digital in: Optical / Coaxial 2 / 2
          Multi-room out: Analog / Digital 1 / –
          Multichannel pre-out • (7.2)
          Subwoofer out 2
          7.1 Multichannel input •
          OTHER
          Speaker terminal: gold plated screw / regular screw – / •
          SPECIFICATIONS
          Number of poweramps 7
          Number of speaker terminals 7
          Power output (8 ohm, 20 Hz – 20 kHz, 0.08% 2ch drive) 100 W
          Power output (8 ohm, 20 Hz – 20 kHz, 0.05% 2ch drive) –
          Power output (6 ohm, 1 kHz, 10% 1ch drive) 200 W
          GENERAL
          System remote control RC035SR
          Power consumption in W 650
          Power consumption no-sound (ECO on / off) in W 45 W / 75 W
          Standby consumption in W 0.2 (with CEC 0.5)
          Maximum dimensions
          w/o antenna: (W x D x H) in mm
          440 x 348 x 161
          Weight in kg: 12.7
          Colour: Black

          The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such
          marks by D&M Holdings Inc. is under license. Dolby, Dolby Atmos, and the double-D symbol are trademarks of Dolby
          Laboratories. DTS, the Symbol, DTS in combination with the Symbol, DTS:X, and the DTS:X logo are registered
          trademarks or trademarks of DTS, Inc. in the United States and/or other countries. The Spotify software is subject
          to third party licenses found here: www.spotify.com/connect/third-party-licenses. Other trademarks and trade
          names are those of their respective owners. Marantz is a trademark or registered trademark of D&M Holdings, Inc.
          *All specs can be subject to change.
