Denon DCD-1700NE CD Player

Description

Enjoy accurate audio reproduction that’s faithful to the original recording. Thanks to technologies like Advanced AL32 Processing Plus and an ultra-precision D/A Converter, you’ll hear your favorite songs like never before. The Denon original drive mechanism with S.V.H lets you play back CDs, SACDs, and your own compilations on DVD R/RW with signal purity.

ADVANCED AL32 PROCESSING PLUS
Experience audio beautifully faithful to the original sound. Advanced AL32 Processing Plus algorithms restore information that was lost during the digital recording.

EXTENDED DISC FORMAT SUPPORT
Enjoy extended disc support for your high-resolution audio collection, including CD’s, Super Audio CDs, as well as DSD and high-res files up to 192 kHz/24 bits recorded on DVD-R/RW and DVD+R/RW discs.

PROPRIETARY DISC DRIVE
The Denon original disc drive is built with a high-class S.V.H (Suppress Vibration Hybrid) mechanism. All elements of the design are focused on delivering optimal accuracy.

DAC MASTER CLOCK DESIGN
To accurately synchronize digital circuits, the DAC master Clock design treats the DAC as the master when clock signals are supplied. Crafted with exceptional quality, the master clock is right next to the DAC, which suppresses jitter and ensures peak precision in D/A conversion. It serves as the reference for semiconductor operation and optimizes digital audio circuitry. Two integrated clock oscillators reduce phase noise, each addressing a sampling frequency (44.1 kHz and 48 kHz)

ADVANCED CIRCUITRY WITH MINIMIZED SIGNAL PATH
Circuit patterns are thoughtfully engineered to make signal paths as short as possible. With shorter circuits, the interference between circuits and left and right channels is reduced, and the adverse influences on audio signals are minimized. As a result, the circuit paths in the DCD-1700NE reproduces sound that’s clean, highly transparent, and faithful to the original recording.

SPECIFICATIONS

Frequency Response
SACD:2Hz – 50kHz (-3dB)
CD:2Hz – 20kHz (-0.5dB)
Harmonic distortion
SACD: 0.0010%
CD: 0.0016%
Signal-to-Noise Ratio
SACD: 119dB
CD: 117dB
Dynamic Range
SACD: 112dB
CD: 101dB
Line Output Level
2.0Vrms (10kohm)

DIGITAL AUDIO

DAC Circuit
TI　Advanced Current Segment
PCM1795(192k/32bit) ×1
Digital Filter
Fixed
Digital Processing
Advanced AL32 Processing Plus
DAC Master Clock Design (Not Support Network Playback)
Yes

DISC

Mechanism
TD-505 FOR DM
Disc Type
SACD/CD/CD-R/CD-RW
DVD-R/+R/-RW/+RW
SACD
Yes (Stereo Layer/Multi-D/M)
Super Audio CD Text
Yes
Playability of files recorded on CD-R/RW :

MP3 / WMA / AAC
Yes / Yes / Yes
WAV
Yes (~48kHz/24bit)
FLAC
Yes (~48kHz/24bit)
ALAC
Yes (~48kHz/24bit)
AIFF
Yes (~48kHz/24bit)

Playability of files recorded on DVD R/RW :

MP3 / WMA / AAC
Yes / Yes / Yes
WAV
Yes (~192kHz/24bit)
FLAC
Yes (~192kHz/24bit)
ALAC
Yes (~96kHz/24bit)
AIFF
Yes (~196kHz/24bit)
DSD (DIFF / DSF
Yes (~5.6MHz)
Firmware Update
Yes (FE/BE, MCU)

INPUTS/OUTPUTS

Fixed Analog Output (RCA)
Cinch x 1 (Gold Plated)
Optical input / output (Maximum Support)
0 / 1
Coaxial input / output (Maximum Support)
0 / 1

CONTROLS

Remote Controller
System Remote
(Amp and CD Player Control)
On-Product Buttons
Power
Disc Layer
Pure Direct
Play/Pause
Stop
Fwd/Rev
Open/Close
LED
POWER: 1 Green
Front Panel Display
Single Line
Dimmer for Front Display
Bright / Dim / Dark / Off
Control with App via Network Player (Use Remote Control Bus)
Yes

OTHER

Pure Direct Mode
Yes
Last Function Memory
Yes
Remote Control Bus Terminal
Yes
Remote Control
Yes
(controllable PMA-1700NE)
Battery
Yes (AAA x2)
Power Cord
Yes
Other
Stereo RCA Cable x1
Timer Play (Need external audio timer)
Yes
Auto Standby Mode
Yes

GENERAL

Unit (W x H x D)
434 x 135 x 384mm
17.09 x 5.31x 15.12
Cabinet Size
434 x 135 x 374
Net weight
9.0kg (19.84 lbs)
Packaging Dimensions (W x H x D mm)
543 x 250 x 515
Packaging gross weight
11.7kg (25.79 lbs)
Power Consumption
24W
at Standby
0.1W
Front (Center) Panel
Aluminum
Function button
Aluminum
Open / Close button
Aluminum
Power button
Aluminum
