Denon DNP-2000NE High Resolution Network Music Streamer

Description

Upgrade any existing audio system to play most digital audio sources—including your television—using HDMI ARC for an improved audio experience. The DNP-2000NE also connects to your home network, so you can enjoy your favorite music services using HEOS® Built-in.

Key Features
Rich connectivity: High-quality audio from your digital and streaming sources.
Faithful audio reproduction: Ultra AL32 Processing delivers the richly detailed sound the artist intended.
Connect directly to your TV: Simple one-cable connection with any compatible HDMI ARC television.
Colors Available: Black, Silver, Graphite

SPECIFICATIONS

Frequency response
DSD: 2 Hz–50 kHz (-3dB)
PCM(44.1 kHz): 2 Hz–20 kHz

Harmonic Distortion
DSD: 0.0006%
PCM: 0.0008% (24 bit)

S/N
DSD: 120dB
PCM: 118dB

Dynamic Range
DSD: 112dB
PCM: 118dB

Line Output Level
2.2Vrms

Variable Output Level
4.5Vrms

Headphone Output Level
150mW/32 ohms
high gain

Power Consumption
38W

at Standby
0.2W

at Network Control On
(all of Bluetooth, Ethernet, Wi-Fi, USB)
Less than 2W

AUDIO FEATURES

Output Circuit
Minimum signal path

Power Transformer
EI transformer

H/P Amp Gain Setting
Yes (Low/Mid/High)

DAC Circuit
384 kHz/32 bit
(ES9018K2M) x4

Digital Filter
Fixed

Digital Processing
ULTRA AL32 Processing

Jitter Reducer
Yes

DAC Master Clock Design
Yes
(Does not support network playback)

Asynchronous Mode (for USB B input)
Yes

Isolator (for USB B input)
Yes (and digital inputs)

CONNECTIVITY

Fixed Analog Output (RCA)
1 L/R independent, gold-plated high-grade brass terminals

Pre/Variable Audio Output (RCA)
1 Pair (gold-plated
elec vol: JRC)

Optical Input/Output (maximum support)
2/1

Coaxial Input/Output (maximum support)
1/1

HDMI Input/Output
1/0 (ARC Only)

Headphone Output
Yes (6.3mm)

Engine (module or main device)
HEOS

Ethernet
Yes

Wi-Fi
2.4 GHz (11b/g/n)
5 GHz (11a/n/ac)

Wi-Fi Antenna
2 external detachable antenna

WPS (Wi-Fi protected setup)
PBC only

Wi-Fi Sharing
Yes (WAC)

WMM
Yes

Wi-Fi Direct
–

OFF mode
Yes

Wireless Multiroom Audio / HEOS / Apple AirPlay2
Yes / Yes

Supported Audio File / MP3 / WMA / AAC / WAV / FLAC / ALAC / DSD (DIFF/DSF)
Yes / Yes / Yes / Yes (~192 kHz/24 bit) / Yes (~192 kHz/24 bit) / Yes (~192 kHz/24 bit) / Yes (~5.6 MHz)

DSD Native Playback
Yes

Gapless Playback
Yes
(WAV, FLAC, ALAC, AIFF, DSD)

Internet Radio
Yes (TuneIn)

Online Music Service / Spotify Connect / Deezer Premium/Deezer HiFi / Sound Cloud / Tidal / Amazon Music Unlimited/Amazon Music HD/Prime Music / Napster / Mood Mix / Other
Yes / Yes / Yes / Yes / Yes/Yes/Yes / Yes / Yes / –

AirPlay
Yes (AirPlay 2)

Roon Certificaton
Yes (Roon Tested)

Firmware Update/Charged Upgrade
Yes / –

USB A
Front x 1

Support format
FAT 16/32, NTFS

Gapless Playback
Yes
(WAV, FLAC, ALAC, DSD)

USB Firmware Update
Yes

USB B (USB DAC)
Rear x 1

Supported Audio File / PCM / DSD / MQA
~384 kHz/32 bit / ~11.2 MHz / –

Roon Certificaton
Yes (Roon Tested/HEOS)

BT Rx
Yes (SBC)

OFF mode
Yes

CONTROLS

App
HEOS app

Remote Controller
Yes
(New system remote controller to control PMA-1700NE)

Unit Control (button)
Tact Switch: 8
Power, Back, Source, Up, Down, Left, Right, Play/Pause

Unit Control (knob)
1
Phones level

LED
Power: 1 red/green

Front Panel Display
OLED 3-line display

Dimmer for Front Display
Bright/Dim/Dark/Off

Voice Assistant
Yes

Works with Amazon Alexa
Yes

Works with Google Assistant
Yes

Works with Apple AirPlay (Siri)
Yes

HDMI CEC
Yes

HEOS Control on Front Panel
Yes

HEOS Favorites Call/Add
Yes

Setup on Front Panel
Yes

Setup Assistant
Yes

TV Auto-Play (opt/coax digital-in detector)
Yes

Last Function Memory
Yes

Volume Limit
Yes

Sleep Timer
Yes

Auto Standby Mode
Yes

KPI (for usage data)
Yes

GENERAL

Unit (W x H x D mm)
434 x 107 x 421
(*includes antenna)

Cabinet Size
434 x 107 x 374

Net weight
9.7 kg

Packaging Dimensions (W x H x D mm)
548 x 210 x 520

Packaging Gross Weight
12.0 kg

Panel Color
Premium Silver/Black/Silver Graphite

Front (Center) Panel
Aluminium

Bottom Layer/Bottom Plate
Double

WHATS IN THE BOX

Quick Start Guide
Yes

Remote Control
Yes

Battery
Yes (AAA x2)

Power Cord
Yes

Other
Stereo RCA cable x1
IR control cable x1
