Description
Ultra AL32 Processing is the latest in analog waveform reproduction technology from Denon.
Power transformers are fitted near the bottom and immediately above the insulators to prevent unwanted vibration. The vibration surrounding the chassis is reduced, resulting in pristine sound.
The ability to decode Hi-Res Audio ALAC, FLAC and WAV lossless files up to 24-bit/192-kHz, as well as DSD 2.8MHz and 5.6MHz tracks (SACD) lets you enjoy each note exactly as the artist intended.
The circuit patterns have been engineered to make signal paths as short as possible, reducing interference to reproduce sound that’s clean, highly transparent, and faithful to the original recording.
Denon Moving Coil (MC) phono preamps feature a low-noise circuit design for minimal signal distortion, and a high-precision equalizer circuit to restore the warmth and natural sound of vinyl.
Denon Moving Magnet (MM) phono preamps feature a high-precision equalizer circuit to restore the warmth and natural sound of vinyl, and a low-noise signal path for improved fidelity.
Pure Direct mode turns the display and the digital outputs off to minimize interference that might color the audio signal. What you hear is clean, detailed, accurate sound.
GENERAL
Unit (W x D x H)
434 x 410 x 135mm
17.1 x 16.1 x 5.3in
Cabinet Size (W x D x H)
434 x 374 x 135mm
17.1 x 14.7 x 5.3in
Net weight
17.6kg
38.8lb
Packaging Dimensions (W x D x H)
548 x 520 x 249mm
21.6 x 20.5 x 9.8in
Packaging gross weight
20.4kg
45lb
Carton Color
2 Color
Cushion / Packing
4 Separate / Sheet
Panel Color
SP / BK
Front (Center) Panel
Aluminum
Side cover
SECC with 4 straight emboss
Side screw
SP: Nickel / BK: Black
Rear Panel
SECC t1.0mm
Chassis Material
SECC t1.2mm
Bottom Layer
Single
Volume Knob
Aluminum
Input Selector
Aluminum
Bass/Treble/Balance/ Phono Sel knobs
Aluminum
Power button
Aluminum
Other knob/button (LOUDNESS, SOURCE DIRECT etc)
Mold (Source Direct,Analog Mode,MM/MC)
Foot
ABS resin with rigid rib
w/Hot stamp
(H : 20mm)
Heatsink for Power Amplifier
Extruded Aluminum
SPECIFICATIONS
Rated Output Power
70W + 70W
(8ohm,20Hz-20kHz,THD0.07%)
140W + 140W
(4ohm, 1kHz, THD0.7%)
Speaker Impedance
A or B : 4 ~ 16ohm
A + B : 8 ~ 16ohm
Frequency Response
5Hz – 100kHz (0~ -3dB)
Total Harmonic Distortion
0.01 % (Rated output: –3 dB),
8 ohm/ohms, 1 kHz
Damping Factor
100 and over
Input Sensitivity: Phono input
MM: 2.5 mV / 47 kohm
MC: 200
RIAA Deviation
20 Hz – 20 kHz ±0.5 dB (MM/MC)
Phono Maximum Input
MM : 130mV / 1kHz
MC : 10mV / 1kHz
Input Sensitivity: CD/LINE/RECORDER
125 mV / 19 kohm
Input Sensitivity: Power Amp input
0.85V / 47kohm (EXT. PRE)
Signal to Noise Ratio
PHONO (MM): (89dB)
PHONO (MC): (74dB)
CD: (107dB)
Tone Control
BASS : 100Hz ±8dB
TREBLE : 10kHz ±8dB
Power Consumption
295W
at Standby
0.2W TV autoplay off
0.4W TV autoplay on
AUDIO FEATURE
Power Amplifier Circuit
New UHC-MOS
Single Push Pull (7)
Power Transformer
Dual El Core
Pre Amplifier Circuit
Variable Gain Preamplifier
(OP AMP)
Volume
Electric
(MUSES 72323)
Bass / Treble / Mid / Balance Control
Yes / Yes / No / Yes
Type of Tone Control
Electric
Controlled by Potentiometer
Headphone Circuit
Use Power amplifier
Source Direct
Yes
Analog Amp Mode
Yes (button on front panel)
DAC Circuit
PCM1795
Digital Filter
Fixed
Digital Processing
Advanced AL32 Processing Plus
DAC Master Clock Design (Doesn’t Support Network Playback)
Yes
Asyncronous mode (for USB-B input)
yes
Isolator (for USB-B input)
Yes
Full Isolation
CONNECTIVITY
Phono Input
Yes (MM / MC)
*default=MM
Analog Input (include Phono) / REC Out (RCA)
4/1 (PHONO/ CD/ AUX/ RECORDER)
Optical input / output (Maximum Support)
2 / 0 (192kHz/24bit)
Coaxial input / output (Maximum Support)
1 / 0 (192kHz/24bit)
Ext. Pre Input (Power Amp Direct)
Yes(Ext.Pre)
2 sets of Speaker Output
Yes (Bi-wiring)
Speaker Terminal
Gold Plated
Headphone Output
1
(Turn off the speaker when inserting headphone)
Remote Control Bus Terminal
Yes (mini)
AC Inlet
Yes
Wi-Fi
No
HEOS
No
USB B (USB DAC)
1 (Rear)
Module or Main Device
New XMOS
(XU210-256-TQ128 )
PCM Sample Rate
~384kHz/32bit
DSD Audio Streaming (DoP)
~11.2MHz
Roon Certificaton
Yes(Roon Tested)
TBD
CONTROL
Remote Controller
System Remote
(w/CD Player Control)
Unit control (Button)
Push Switch: 1
POWER
Tact Switch : 3
ANALOG MODE, SOURCE DIRECT, MM / MC
Unit control (Knob)
5
VOLUME, INPUT SELECTOR, BASS, TREBLE, BALANCE
LED
POWER: 1 Red / Green
ANALOG MODE: 1 Green
SOURCE DIRECT: 1 Green
MM / MC :1 Green
Front Panel Display
Yes
(OLED 128 x 100 dot)
MXS4036-A
Display Language
Alphabetical
Dimmer for Front Display
Bright / Dim / Dark / Off
Control with App via Network Player (Use Remote Control Bus)
Yes
TV Auto-play (Opt/Coax digital-in detector)
Yes
Last Function Memory
Yes
Auto Standby Mode
Yes
Owner’s Manual
Web Manual
E2: (English, German, French, Italian, Dutch, Spanish,
Swedish, Polish, Russian)
E3: (English, French, Spanish)
E1C: (Simplified Chinese)
JP: (Japanese)
Paper
JP: (Japanese)
Quick Start Guide
Paper
E2: (English, German, French, Italian, Dutch, Spanish,
Swedish, Polish, Russian)
E3: (English, French, Spanish)
E1C: (Simplified Chinese)
JP: (Japanese)
Remote Controller
Yes
Battery
Yes (AAA x2)
Power Cord
Yes
