Description
KEY FEATURES
• Detailed and immersive sound transforms your listening room
• Beautiful design matches rich, warm sound
• 9.4 channel output allows a variety of speaker layouts
• 125-watts-per-channel amplifier creates realistic dynamics
• Decodes Dolby Atmos, DTS:X audio, and Auro 3D
• Acoustic room tuning with Audyssey MultEQ XT32
• Seven HDMI inputs (all 8K) and three outputs for highestresolution video
• Sound Master tuned for warm, rich, and detailed Marantz sound
• Attractive new HD on-screen interface makes setup intuitive
• Pre-amp outputs for all channels
SPECIFICATIONS
POWER AMPLIFIER
Number of Powered Channels: 9
Power Output (8 ohm, 20 Hz – 20 kHz, 0.05% 2ch Drive): 125 W
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive): 165 W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive): 235 W
70% Guarantee: Yes
Discrete Power Amplifier: Yes
Amplifier Topology: Class A/B
Current Feedback Topology: Yes
Bi-Amp Drive: assignable
MULTICHANNEL SURROUND TECHNOLOGIES
DTS: DTS HD Master, DTS:X, DTS Neural:X, DTS Virtual:X
Dolby: Dolby TrueHD, Dolby Atmos, Dolby Atmos Height Virtualization, Dolby Atmos Music, Dolby Surround
Other: IMAX Enhanced, Auro-3D, 360 Reality Audio, MPEG H, Audyssey DSX, Multichannel Stereo
Max Number of Processing (Preamp) Channels: 11.4
INPUTS/OUTPUTS
Composite In / Out: 2 / 0
Component In / Out: 1 / 0
HDMI In / Out: 7 / 3
Multi-Room Video Out via HDMI: Yes
Analog In / Fixed Level Out: 6 in / 0 out
Phono (MM) In: Yes
Digital In: Optical / Coaxial: 2 / 2
Multi-Room Out: analog / digital: 2 / 0
Multichannel Preamp Out: 11.4
Subwoofer Out: 4 (independent)
7.1 multichannel input: Yes
Number of Speaker Terminals: 11
Speaker A / B: assignable
Multi-Room Speaker Terminal: assignable
Front Inputs: USB-A
USB Audio: Yes
FM Tuner with RDS: No
DAB+ Tuner: No
HDMI
Total HDMI Inputs / No. Support 8K: 7 / 7
HDCP2.3 support: Yes
HDMI Outputs: Main / Zone: 2 / 1
Analog to HDMI Video Conversion: Yes
HDMI Upscaling: 1080P/4K to 8K
Max resolution @ framerate: 8K @ 60Hz, 4K @ 120Hz
Audio Return Channel: eARC
Video Dynamic Range: HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR
ALLM (Auto Low Latency Mode) Pass-through for gaming: Yes
Variable Refresh Rate / Quick Frame Transport: Yes / Yes
HDMI Pass-Through in Standby Mode: Yes
CEC: Yes
DSD Audio over HDMI: Yes
Auto LipSync: Yes
PERFORMANCE TECHNOLOGIES
Copper Plated Chassis: No
Toroidal Power Supply Transformer: No
Hyper Dynamic Amplifier Modules (HDAM) (List version): Yes
Pure Direct Mode: Yes
Gold Plated RCA Terminals: Yes
Clock Jitter Reducer: Yes
ACOUSTIC/ROOM CORRECTION
Audyssey: MultEQ XT32
Audyssey Dynamic EQ / Dynamic Volume: Yes / Yes
Audyssey LFC: Yes / Yes
Dirac Live Support: Yes
Variable Cross Over: Yes
Optimized Bass Redirection: Yes
Bass Sync: Yes
MUSIC FILE SUPPORT
Lossy Formats: MP3 / WMA / AAC
Lossless formats: FLAC HD 192/24 / WAV 192/24 / ALAC 192/24
DSD Audio: 2.8MHz / 5.6MHz
Gapless Playback: FLAC, WAV ,ALAC ,DSD
Compressed Audio Enhancer: MDAX2: Yes
Network Audio Sharing: Yes
STREAMING SERVICES
HEOS Multi-room and Streaming: Yes
AirPlay Audio Streaming: Airplay 2
Internet Radio: TuneIn
Spotify*: Spotify Connect
Pandora: Yes
SiriusXM Yes
Other Streaming Services *: Amazon Music HD/
Amazon Music / TIDAL / Deezer / Napster / Soundcloud / Mood Mix
Roon tested: Yes
NETWORK CONNECTIVITY
Ethernet Ports: Yes
Wi-Fi (include version / band): Yes
Bluetooth (Include version): Yes
Bluetooth Re-transmit for Bluetooth headphones: Yes
SMART HOME INTEGRATION AND CONTROL
Voice Assistant Compatibility: Alexa / Google Voice Assistant / Apple HomePod
App for Smart Phones & Tablets (iOS & Android): Marantz AVR App, HEOS
HEOS Multi-Room Integrated: Yes
HEOS Link Compatibility: IR/ IP Yes / Yes
Multi-Room zones: 3
Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog: 2 Ch / 2 Ch / Yes / Yes
Zone Audio Output: Speaker / Preout: Yes / Yes
Zone HDMI Output from HDMI Source: Yes
Control Connectivity: IP Control / RS232 Control / Web Control / App Control
IR Flasher In: Yes
Marantz Remote Bus: Yes
DC Trigger Output: 3
HDMI Diagnostics: Yes
OTHERS
Front Display: 2 line FLD + port hole OLED
GUI Languages: 9
Setup Assistant: Yes
Smart Select on Remote: Yes
Firmware Update by Network / USB: Yes / Yes
ECO Mode: Yes
Auto Power off: Yes
Sleep Timer: Yes
GENERAL
Availabe colours: Black
Metal Front Panel: Yes
System Remote Control: RC-048SR
Power Consumption in W: 710
Power Consumption No-Sound (ECO on/off) in W: 65 W / 110 W
Standby Consumption in W: 0.2
CEC Standby Consumption in W: 0.5
Network Standby Consumption in W: Less than 2.0
Maximum Dimensions
Antenna:Horizontal:(W x D x H) in mm: 440x414x185
Antenna:Vertical :(W x D x H) in mm: 440x414x254
W/o Antenna:(W x D x H) in mm: 440x401x185
Weight in kg: 15.1
What’s in the box: Main unit, remote control, batteries, wire labels, quick start guide, Audyssey microphone, microphone stand, 2 External Detachable Antenna, AC cord
