Description
Key Features
- Crafted in Shirakawa, Japan
- 2.1 Channels
- 100 Watts per Channel
- HDMI eARC
- Dolby Digital+
- HEOS Built-in
True Marantz Power
MODEL M1’s 100W per channel of high-quality, low-distortion amplification delivers pristine sound anywhere, while a subwoofer output delivers room-filling scale in larger spaces.
High Resolution Digital Direct
However you choose to stream your high-resolution music, MODEL M1 has you covered, with support for HEOS, AirPlay2, Bluetooth, Spotify Connect, and more.
Marantz Multi-Room
The expansive feature set yet diminutive size of M1 makes it the ideal partner for multi-room listening.
Marantz Musical Digital Filtering
MMDF is a unique and sophisticated digital filtering technology that reveals the natural detail and tonality in sound.
TV Sound: Marantz Quality, Soundbar Simplicity
Unveil superb sound from movies and TV programs with MODEL M1 using HDMI eARC and onboard Dolby Digital+ processing.
SPECIFICATIONS
AMPLIFIER
Power Amplifier Rated output & THD (8 ohm): 100W+100W (8Ω/ohms, 20 Hz to 20 kHz, T.H.D. 0,05%)
Power Amplifier Rated output & THD (4ohm): 125 W + 125 W (4Ω/ohms, 1 kHz, T.H.D. 0.05%)
Frequency Response: 20 Hz to 20 kHz : ±1 dB
Connected loudspeaker Impedance Audio Inputs / Outputs: 4 – 16 Ω/ohms
AUDIO INPUTS/OUTPUTS
Loudspeaker Binding Posts: 4-way binding posts
Digital Inputs: HDMI (eARC), TOSLINK
Analogue Inputs: RCA L/R
Subwoofer Out: RCA Mono
AUDIO OPTIONS
Channel Assignments: Stereo (Default), Dual Mono
Volume Limit: 80-100%
Balance: -15dB to +15dB
Adjustable High Pass / Low Pass Filters: 40-250 Hz / 40-120 Hz
EQ: Bass, Treble -5dB to +5dB
Sound Modes: Stereo, Direct, Virtual,Dialog Enhancer, Night Mode
TV Sound Grouping: Yes
AUDIO FORMAT SUPPORT
Decoding: Dolby Digital +, Dolby Digital, LPCM, DSD
Stereo PCM / Multi-channel PCM: Yes / Yes
Stereo File Formats (HEOS network share or USB): WMA: up to and including 192 kbps, AAC & MP3: up to and including 320 kbps,WAV, ALAC, FLAC: up to and including 24-bit/192kHz, DSD: 2.8 MHz, 5.6MHz
STREAMING TECHNOLOGIES
Bluetooth Receive: BT 5.X
Bluetooth Transmit: No
AirPlay: AirPlay 2
Spotify: Spotify Connect
MUSIC SERVICES AND SOURCES
Music Services Supported: (HEOS, subject to change and local availability) Spotify, TuneIn, Amazon Music, Tidal, Tidal HiRes, Deezer, Deezer HiFi, Mood:Mix, Sony Hi- Res, SoundCloud
Music stored on mobile device: Yes (iOS, Android or Kindle Fire)
NAS (Network Attached Storage): Network share, DLNA
USB Storage Device Playback: Yes (FAT32, NTFS formatted drives)
NETWORKING & CONTROL
Wired Connectivity: Ethernet
Wireless Connectivity: Dual band, 802.11 a/b/g/n/ac
IR Input: 3.5mm
IR Learning: Yes
Control System Compatibility via TCP/IP: Crestron, Control4, AMX
HEOS App: iOS, Android
GENERAL
Available Colors: Black
User Interface: Volume up/down, Play / Pause, Multi coloured LED status indicator, Connect button (rear), Bluetooth button (rear)
Dimensions (W x D x H) mm: 217 x 239 x 84
Weight in kg: 2.2
