Marantz Model 50 Stereo Integrated Amplifier

Description

With a precisely engineered Class A/B amplifier, MODEL 50 will drive your loudspeakers with authority yet reveal details you never knew existed.

The Marantz Sound Master meticulously tuned MODEL 50 for amazing performance with careful parts selection to create the Most Musical Sound in your home.

The built-in MM phono stage works with your turntable to amplify the nuance and tone in your records. Using a new circuit without distortion-inducing coupling capacitors.

MODEL 50’s stereo preamp outputs add valuable flexibility to your audio system setup. Connect a subwoofer, add channels to your home theater, or multiply listening zones—the possibilities are endless.

FEATURES

Channels
2
Current Feedback Topology
Yes
Phono EQ: Standard / Marantz Musical / Marantz Musical Premium
– / Yes / –
Digital in: USB-B / optical / coaxial / USB-A
– / – / – / –
HDAM version
SA3, SA2
Power Transformer: Toroidal / El
Yes / –
High Grade Audio Components
Yes
Customised Components
Yes
Symmetric PCB Layout
Yes
Aluminium extrusion heat sink
Yes
Balance / Bass / Treble / Loudness
Yes / Yes / Yes / –

OTHERS

Linear Drive Power Supply
Yes
Linear Volume Control
Yes
Schottky diodes
Yes
Input buffer amp (all inputs / CD only)
– / –
Solid Heat Sinks
Yes
System block shielding: Copper / metal / none
none
Bottom Plate
triple
Low noise OLED display
Yes
Source Direct
Yes
Power Amp direct
Yes

INPUTS/OUTPUTS

Audio Inputs
6
Digital in: USB-B / optical / coaxial / USB-A
– / – / – / –
Phono Input: MM / MC
Yes / –
Audio Outputs
1
Balanced In / Out
– / –
Pre-out / Main-in
Yes + subwoofer / –
Power Amp Direct IN
Yes
Gold Plated Cinch
Yes
Speaker A / B
Yes
Speaker Terminals
Marantz SPKT-1+
Number of terminals
4
D-Bus
Yes
Headphone Out
Yes

SPECIFICATIONS

Power Output (8 / 4 Ohm RMS)
70 W / 100 W
Frequency Response
5 Hz–100 kHz
Total Harmonic Distortion
0.02 %
Damping Factor
100
Input Sensitivity: MM
1.4 mV / 47 kΩ
Signal to Noise Ratio: MM/MC
87 dB / –
Input Sensitivity: High level
185 mV / 16 kΩ
Signal to Noise Ratio: High level
116 dB (2 V input)
Input Sensitivity: Power Amp Direct IN
1.5 V / 15 kΩ
Signal to Noise Ratio: Power Amp Direct IN
125 dB
Treble Control
± 10 dB at 15 kHz
Bass Control
± 10 dB at 50 Hz

GENERAL

Available Colors: Gold / Silver / Black / Silver-Gold
– / – / Yes / Yes
Metal Front Panel
Yes
Power Consumption in W
220
Standby Consumption in W
0.3
Auto Power off
Yes
Detachable Power Cable
Yes
Remote Control
RC003PMND
System Remote Function
Yes
Maximum Dimensions (W x D x H) in mm
442 x 431 x 130
Weight in kg
14.2
Carton Maximum Dimensions (W x D x H) in mm
527 x 517 x 255
Carton Weight (inc. product) in kg
17.5
