Anthem MRX 1140 8K 11.2 Channel A/V Receiver / 15.2 Pre-Amplifier

Description

Advanced 8K HDMI Platform
with e-ARC Support
Feel the power of every frame with the MRX Series and its advanced 8K HDMI 2.1 Platform with HDCP 2.3. Showcasing 7 dedicated 8K inputs which support 8K/60Hz or 4K/120Hz pass-through and 3 dedicated outputs with Enhanced Audio Return Channel, you can enjoy 8K quality video from all of your 8K source devices in amazing clarity. Also featuring the latest HDMI technology and specification, the MRX 540, 740 and 1140 allow you to take your home entertainment to the next level with HDR10+, Dynamic HDR10+, ALLM and VRR support. The possibilities are limitless; unlock the true potential of your media with the industry’s most flexible and feature-rich HDMI platform.

Experience Gaming Like Never Before on an MRX
It’s never been a more exciting time to be a gamer. With the latest consoles offering up to 4K/120Hz graphics, realistic HDR and Dolby Vision dynamic range, and immersive Dolby Atmos sound, you have to make sure your Home Theater gear won’t hold you back. Enter the MRX Series, our most feature-rich AV receivers to date!

FEATURES

• Toroidal Power Supply
• 32-Bit/768 kHz DAC
• Two Independent Subwoofer Outputs
• Wi-Fi / Ethernet Enabled
• IP and Serial Control
• Dolby Atmos
• DTS:X, DTS Virtual:X
• HDMI eARC
• Apple AirPlay 2
• Google Chromecast (Audio)
• Bluetooth v4.2
• Spotify Connect
• 32-Bit/768 kHz DAC
• Wi-Fi / Ethernet Enabled
• IP and Serial Control
• Dolby Atmos
• DTS:X, DTS Virtual:X
• HDMI eARC
• Apple AirPlay2
• Google Chromecast (Audio)
• Bluetooth v4.2
• Spotify Connect
• 32-Bit/768 kHz DAC
• Wi-Fi / Ethernet Enabled
• IP and Serial Control
• Dolby Atmos
• DTS:X, DTS Virtual:X
• HDMI eARC
• Apple AirPlay2
• Google Chromecast (Audio)
• Bluetooth v4.2
• Spotify Connect

HDMI & VIDEO

• Dolby Vision
• IMAX Enhanced
• HDMI 2.1 & HDCP 2.3
• HDMI eARC
• 4:4:4 Subsampling @ 8K/60 Hz (18.2 Gbps)
• High Dynamic Range (HDR10+)
• Variable Refresh Rate (VRR)
• Auto Low Latency Mode (ALLM)
• Quick Frame Transport
• Hybrid Log Gamma (HLG)
• BT.2020 Color Gamut
• 8K/60 Hz / 4K/120 Hz Pass-Through
• Zone 2 HDMI Output

Custom Installation:
IP Control
RS-232 Control
IR Input
Three 12V Trigger Outputs
Pre-made Control Drivers
Save and Load Settings
Import and Export Settings
Rackmount kit (sold separately)

Listening Modes:
Anthem Logic
Dolby Surround
DTS Neural:X
DTS Virtual:X
Stereo
All Channel Stereo
Mono
All Channel Mono

Additional Features:
Anthem Web User Interface
Advanced Load Monitoring (ALM)
30 Input Configurations
Input trim adjustments
Power-on Input Assignment
Auto Power Off
Eco Mode (standby)
Over-the-air Network updates
USB updates
Beta updates (over-the-air)
Backlit Remote Control
Toroidal Transformer

MAXIMUM CONTINUOUS OUTPUT (1% THD)
Channels 1-5, Two Driven into 8 Ohms: 140 W
Channels 1-5, Two Driven into 6 Ohms: 170 W
Remaining Channels, Two Driven into 8 Ohms: 60 W
Remaining Channels, Two Driven into 6 Ohms: 75 W

PREAMPLIFIER
Maximum Output (<0.1% THD) 5.2 VRMS, 7.1VRMS
Frequency Response 20Hz – 30KHz +/-0.2dB
Frequency Response, Analog-Direct N/A
THD+N (2 Vrms output) -100 dB
S/N Ratio (2 Vrms output, IEC-A filter) 110 dB

Dimensions (WxHxD): 432 x 166 x 336mm (382mm including knobs & connections)
Weight:15.2 kg
