Anthem MRX 1140 11.2 Channel A/V Receiver / 15.2 Pre-Amplifier

Brand:

Anthem

15.2 Pre-Amplifier / 11 Amplifier Channel A/V receiver with Dolby Atmos, DTS:X and IMAX Enhanced. 140-watts per channel continuous power into 8 ohms. Includes ARC (Anthem Room Correction). HDMI v2.1 8K Upgradeable.

$6,499.00

Description

Features include:

New Electronics platform, up to 15.2 pre-amplifier channels with 11 amplifier channels, HDMI 2.0b HDCP 2.2, hardware upgradeable to HDMI 2.1 (8K)
On select models (MRX 1140, AVM 90 and AVM 70), object-oriented audio codecs have been updated to the latest version of DTS:X Pro.
All object-oriented audio codecs have been updated to the latest version of DTS:X and Dolby Atmos.
IMAX Enhanced
ARC Genesis now features a more precise microphone, ensuring better results in any listening environment.
Platform Agnostic Streaming with AirPlay2, Google Chromecast (Audio), Bluetooth v4.2, and Spotify Connect and Roon (coming soon!)
Reliable Networking Platform with web-based setup and over-the-air updates
Next-Generation DSP Platform
Modernized Design with high-resolution front panel display
Amp matrixing with up to 10 re-assignable channels
Two Independent sub outputs on MRX 1140, allow ARC Genesis to correct multiple subs individually for frequency response and phase alignment.
Independent HDMI Zone 2 output.

Audio Features:
15.2 pre-amplifier channels with 11 amplifier channels. 140 watts per channel continuous power into 8 ohms.
Amp matrixing with up to 10 re-assignable channels
Two independent subwoofer outputs
Auto Subwoofer Phase Adjustments (ARC Genesis)
Auto Subwoofer Polarity Adjustments (ARC Genesis)
Latest Implementation of ARC Genesis
Four Speaker Profile Memories
2” / 5 cm Speaker Distance Increments
0.5dB Level Increments
Super Sub Front Setting

HDMI & Video:
Dolby Vision
IMAX Enhanced
HDMI 2.0b & HDCP 2.2 (hardware upgradeable to HDMI 2.1 8K)
HDMI eARC
4:4:4 Subsampling @4K60 (18.2 Gbps)
High Dynamic Range (HDR)
Hybrid Log Gamma (HLG)
BT.2020 Color Gamut
4K 50/60 Switching
Zone 2 HDMI Output
Dual HDMI Outputs
Standby Pass-Through

Decoding:
Dolby Atmos
Dolby HD
DTS:X Pro
DTS:X
DTS-HD Master Audio

Custom Installation:
IP Control
RS-232 Control
IR Input
Three 12V Trigger Outputs
Pre-made Control Drivers
Save and Load Settings
Import and Export Settings
Rackmount kit (sold separately)

Streaming:
Apple Airplay
Apple Airplay 2
Google Chromecast Audio
Bluetooth
Spotify Connect (coming soon!)
Roon (coming soon!
)
Listening Modes:
Anthem Logic
Dolby Surround
DTS Neural:X
DTS Virtual:X
Stereo
All Channel Stereo
Mono
All Channel Mono

Additional Features:
Anthem Web User Interface
Advanced Load Monitoring (ALM)
30 Input Configurations
Input trim adjustments
Power-on Input Assignment
Auto Power Off
Eco Mode (standby)
Over-the-air Network updates
USB updates
Beta updates (over-the-air)
Backlit Remote Control
Toroidal Transformer

MAXIMUM CONTINUOUS OUTPUT (1% THD)
Channels 1-5, Two Driven into 8 Ohms: 140 W
Channels 1-5, Two Driven into 6 Ohms: 170 W
Remaining Channels, Two Driven into 8 Ohms: 60 W
Remaining Channels, Two Driven into 6 Ohms: 75 W

PREAMPLIFIER
Maximum Output (<0.1% THD) 5.2 VRMS, 7.1VRMS Frequency Response 20Hz - 30KHz +/-0.2dB Frequency Response, Analog-Direct N/A THD+N (2 Vrms output) -100 dB S/N Ratio (2 Vrms output, IEC-A filter) 110 dB Dimensions (WxHxD): 432 x 166 x 336mm (382mm including knobs & connections)
Weight:15.2 kg
