Description
BOWERS & WILKINS 603 S3
Layered, beautiful details
The new 603 S3 introduces our all-new Titanium Dome tweeter, which combines exceptional resolution and insight with smooth, refined high-frequency reproduction. The result? An accurate and immersive insight into your favorite music.


Truly amazing sound
603 S3 introduces our new and even more acoustically transparent tweeter grille mesh, first developed for our revered Signature models. Alongside the new Titanium Dome tweeter, the resolution and realism is exceptional.


Precision and transparency
Thanks to its composite construction, the Continuum cone avoids the abrupt transitions in behavior that can impair the performance of a conventional drive unit. With 603 S3, experience a more open, neutral performance that delivers voices and instruments with precision and transparency.


SPECIFICATIONS
Technical features
Decoupled Double Dome Titanium tweeter
Continuum™ cone FST™ midrange
Paper bass cones
Flowport™
Description
3-way vented-box system
Drive units
1x ø25mm (1 in) Titanium Dome high-frequency
1x ø150mm (6 in) Continuum cone FST midrange
2x ø165mm (6.5 in) Paper bass cone
Frequency range
-6dB 29Hz – 33kHz
Frequency response
(+/-3dB from reference axis)
46Hz – 28kHz ±3dB
Sensitivity
(on axis at 2.83Vrms at 1m)
90dB
Harmonic distortion 2nd and 3rd harmonics (90dB, 1m on axis)
<1% 100Hz – 22kHz
<0.5% 350Hz – 12kHz
Nominal impedance
8Ω (minimum 3.0Ω)
Recommended
amplifier power
30W – 200W into 8Ω on unclipped programme
Dimensions
Height: 985 mm (38.8 in) cabinet only
1,020 mm (40.2 in) including plinth
Width:190 mm (7.5 in) cabinet only
260 mm (10.2 in) including plinth
Depth: 340 mm (13.4 in) cabinet only
368 mm (14.5 in) including grille
and terminals
402 mm (15.8 in) including plinth
Net weight: 27.5kg (60.6lbs)
Finishes
Cabinet:
Black
White
Oak
Red Cherry (APAC only)
Grille:
Black (Black and Red Cherry)
Grey (White and Oak)
MARANTZ M1
Key Features
- Crafted in Shirakawa, Japan
- 2.1 Channels
- 100 Watts per Channel
- HDMI eARC
- Dolby Digital+
- HEOS Built-in
True Marantz Power
MODEL M1’s 100W per channel of high-quality, low-distortion amplification delivers pristine sound anywhere, while a subwoofer output delivers room-filling scale in larger spaces.
High Resolution Digital Direct
However you choose to stream your high-resolution music, MODEL M1 has you covered, with support for HEOS, AirPlay2, Bluetooth, Spotify Connect, and more.
Marantz Multi-Room
The expansive feature set yet diminutive size of M1 makes it the ideal partner for multi-room listening.
Marantz Musical Digital Filtering
MMDF is a unique and sophisticated digital filtering technology that reveals the natural detail and tonality in sound.
TV Sound: Marantz Quality, Soundbar Simplicity
Unveil superb sound from movies and TV programs with MODEL M1 using HDMI eARC and onboard Dolby Digital+ processing.
SPECIFICATIONS
AMPLIFIER
Power Amplifier Rated output & THD (8 ohm): 100W+100W (8Ω/ohms, 20 Hz to 20 kHz, T.H.D. 0,05%)
Power Amplifier Rated output & THD (4ohm): 125 W + 125 W (4Ω/ohms, 1 kHz, T.H.D. 0.05%)
Frequency Response: 20 Hz to 20 kHz : ±1 dB
Connected loudspeaker Impedance Audio Inputs / Outputs: 4 – 16 Ω/ohms
AUDIO INPUTS/OUTPUTS
Loudspeaker Binding Posts: 4-way binding posts
Digital Inputs: HDMI (eARC), TOSLINK
Analogue Inputs: RCA L/R
Subwoofer Out: RCA Mono
AUDIO OPTIONS
Channel Assignments: Stereo (Default), Dual Mono
Volume Limit: 80-100%
Balance: -15dB to +15dB
Adjustable High Pass / Low Pass Filters: 40-250 Hz / 40-120 Hz
EQ: Bass, Treble -5dB to +5dB
Sound Modes: Stereo, Direct, Virtual,Dialog Enhancer, Night Mode
TV Sound Grouping: Yes
AUDIO FORMAT SUPPORT
Decoding: Dolby Digital +, Dolby Digital, LPCM, DSD
Stereo PCM / Multi-channel PCM: Yes / Yes
Stereo File Formats (HEOS network share or USB): WMA: up to and including 192 kbps, AAC & MP3: up to and including 320 kbps,WAV, ALAC, FLAC: up to and including 24-bit/192kHz, DSD: 2.8 MHz, 5.6MHz
STREAMING TECHNOLOGIES
Bluetooth Receive: BT 5.X
Bluetooth Transmit: No
AirPlay: AirPlay 2
Spotify: Spotify Connect
MUSIC SERVICES AND SOURCES
Music Services Supported: (HEOS, subject to change and local availability) Spotify, TuneIn, Amazon Music, Tidal, Tidal HiRes, Deezer, Deezer HiFi, Mood:Mix, Sony Hi- Res, SoundCloud
Music stored on mobile device: Yes (iOS, Android or Kindle Fire)
NAS (Network Attached Storage): Network share, DLNA
USB Storage Device Playback: Yes (FAT32, NTFS formatted drives)
NETWORKING & CONTROL
Wired Connectivity: Ethernet
Wireless Connectivity: Dual band, 802.11 a/b/g/n/ac
IR Input: 3.5mm
IR Learning: Yes
Control System Compatibility via TCP/IP: Crestron, Control4, AMX
HEOS App: iOS, Android
GENERAL
Available Colors: Black
User Interface: Volume up/down, Play / Pause, Multi coloured LED status indicator, Connect button (rear), Bluetooth button (rear)
Dimensions (W x D x H) mm: 217 x 239 x 84
Weight in kg: 2.2
