Denon AVC-X6800H 11.4 Channel AV Amplifier

Description

POWERFUL 11-CHANNEL AMPLIFIER
Featuring a sophisticated power amplifier in monolithic board design, the AVC-X6800H delivers high-power performance at 205 watts per channel to ensure a dynamic and precise entertainment experience.

3D AUDIO EXPERIENCE
Get enveloped in sound with Dolby Atmos®, DTS:X®, IMAX Enhanced and Auro 3D, along with Dolby Surround, DTS Neural:X and Auro-Matic upmixer to optimize legacy content.

CONFIGURATION FLEXIBILITY
AVC-X6800H offers many setup options and flexibility to adjust your home theatre to meet your needs. Supports 13.4 channel processing capability, Pre-Amplifier mode, Audyssey MultEQ XT32, and optional Dirac Live and Dirac Live Bass Control upgradability (with fee).

AL32 Processing technology
AL32 Processing, a Denon proprietary analogue waveform reproduction technology, supports up to 192 kHz sampling frequency and performs a 32bit expansion on your amplifier. The technology thoroughly suppresses noise associated with D/A conversion to reproduce the low-level signals with optimum clarity that will bring out all the delicate nuances of the music. AL32 Processing Multi-Channel means the technology is applied on all channels and all input sources.

DTS:X
DTS:X immersive audio content places sound where it would naturally occur in space, creating life-like, multi-dimensional audio. DTS Neural:X upmixer offers improved immersion and heightened realism for legacy content.

Auro 3D
Auro-3D® elevates the home theatre experience to amazing new levels by delivering the excitement of three-dimensional sound for music, games, broadcast, and films, putting you in a cocoon of life-like sound. Turn your existing audio-visual collection into an Auro 3D experience, thanks to Auromatic upmixing engine.

HDMI connectivity with ARC/eARC
Supports the latest technology on all HDMI inputs and output. ARC (Audio Return Channel) or eARC (Enhanced Audio Return Channel) makes playing TV audio through your AV amplifier simple, with just a single HDMI connection.

eARC provides HD and 3D audio transmission such as Dolby TrueHD, DTS HD Master Audio and Dolby Atmos while ARC is limited to conventional 5.1ch audio formats or PCM.

Brilliant colour from HDR 10+
Supports HDR (High Dynamic Range), HLG (Hybrid Log Gamma), as well as Dynamic HDR and HDR10+ pass-through. HLG offers HDR technology over broadcast content. Both Dynamic HDR and HDR10+ use dynamic metadata to optimize shadows and highlights as screens change.

Next-generation gaming
Supports Variable Refresh Rate (VRR), Quick Frame Transport (QFT) and Auto Low Latency Mode (ALLM) for smooth, lag-free gaming experience when connected with the compatible gaming devices.

High-resolution audio
Discover the incredible fidelity of high-resolution audio tracks and enjoy music as the artist intended. Streaming from a NAS and the front USB port support up to 24bit/192kHz and DSD5.6 hi-res audio playback. Supported audio formats are MP3, WMA, WAV, MPEG-4/AAC, FLAC, ALAC, and DSD.

Apple Siri
With Siri compatibility, users can play music, adjust volume, and switch inputs using voice control. AirPlay 2 features in compatible devices can also be controlled with your voice via Siri.

Audyssey premium suites of room-correction technology
Denon AV amplifiers use the Audyssey suite of EQ software for simple, accurate set-up and calibration. With the supplied Audyssey measuring microphone, Audyssey measures all the speakers in your home theatre, and tunes the AV amplifier to provide the smoothest, most optimal overall listening experience for your room. This AV amplifier supports Audyssey MultEQ XT32 and SubEQ HT, Audyssey’s highest room correction technology. The other supported Audyssey features are Dynamic EQ, Dynamic Volume and LFC (Low Frequency Containment)

Subwoofer outputs and settings
Immerse yourself in evenly distributed, accurate bass. Featuring up to four subwoofer outputs to smooth out low frequencies and provide better dispersion. No audible peaks or dips—just powerful, room-filling bass.

Tweak your subwoofer settings to your preference when more than two subwoofers are connected. Select “Standard” if you want evenly distributed bass performance. Select “Directional” if you want more directional bass performance seamlessly integrated into the speaker channel closest to each subwoofer in the room.

Multi Source Room
This AV receiver supports two source, two-zone audio. Enjoy surround sound in the main room and a separate source in the second room, or play the main audio source so everyone in your home can enjoy.

Dirac Live upgradeability
Purchase a Dirac Live® Room Correction and Dirac Live Bass Control license key to apply state-of-the-art, patented algorithms to analyze and digitally reduce room impact and enhance speaker performance. Visit dirac.com/denon/ for more information.

Dolby Atmos
Feel every dimension in Dolby Atmos®. Upgrade your home theatre with height speakers to unleash a fully immersive 3D audio experience from Dolby Atmos content. Dolby Surround upmixer engages all speakers to create 3D audio sensation from legacy content. Dolby Atmos Height Virtualization Technology creates the sensation of overhead sound even without height speakers.

IMAX Enhanced
Get the most premium at-home entertainment experience with IMAX Enhanced—the latest technology from DTS that sets a new standard for home theatre imaging, sound, scale and clarity. Watch clearer pictures and brighter images. Feel immersive, heart-pounding audio and experience premium content digitally remastered by IMAX.

360 Reality Audio
Immerse yourself in sound as real as if you are at a live concert or with the artist recording in a studio. With 360 Reality Audio, music has never been so real.

8K / HDCP 2.3
Enjoy pristine 8K picture quality on your 8K TV or projector. Supports both 8K pass-through and 8K upscaling of 1080p or 4K content. Supports HDCP 2.3, the latest copy protection standard, for peace of mind when streaming copy protected content.

Dolby Vision
Dolby Vision is a stunning HDR imaging technology that brings extraordinary colour, contrast, and brightness to the screen. Compatible with Dolby Vision so you can enjoy Dolby Vision content from a compatible source device and TV.

HEOS Built-in
With HEOS® Built-in, your AV amplifier can stream music wirelessly across compatible HEOS components from a variety of free and premium streaming services. Consumers can also enjoy their favourite music in any room of the home wirelessly. Play the same song in every room or select a different song for each connected room via a variety of streaming sources. Add Denon Home speakers to more rooms and control it all with the HEOS app.

AirPlay 2
Stream audio or video from your favorite streaming services using your smart device. Hear audio perfectly synced to your speakers from AirPlay 2 sources. AirPlay 2 also supports multi-room audio.

Bluetooth
Connect and play music directly from your smartphone, tablet or other compatible device

Audyssey MultEQ Editor app
You can go even further with the Audyssey MultEQ Editor app, going “under the hood” to view and adjust settings for detailed tuning—allowing you to customize the sound more precisely to the specific problems in your room, and tailor the sound to your personal preferences. With this comprehensive app, you can harness the power of Audyssey MultEQ to take total control of the way your home cinema sounds. The app is available for purchase in iOS and Google Play stores.

Pre-Amplifier Mode
Your Denon AV amplifier can work as a perfect AV preamplifier with the latest HDMI connectivity. Pre-Amplifier Mode provides a cleaner signal path and more tolerance in clipping level by disconnecting internal amplifiers.

Add the flexibility to disconnect select speaker channels so that you can use the AV amplifier’s built-in amplification to drive non-critical channels to get a clearer signal path for the channels driven by external amplification.

Setup assistant
Award-winning guide Denon Setup Assistant provides simple, clear instructions to get started. Just connect your AV amplifier to your TV and follow the instructions on the TV screen in high definition to connect your speakers, perform speaker measurements and connect source devices. For additional convenience, the AV amplifier renames HDMI inputs automatically when connected or you can rename manually at your convenience.

Domotz Pro and OvrC remote
Domotz Pro and OvrC remote system monitoring and management technology programs allow custom integrators to monitor the status of connected products and troubleshoot remotely.

SPECIFICATIONS

MULTICHANNEL SURROUND

DTS-HD Master Audio / DTS:X
o / o

DTS:X Pro
o

DTS Neo:6 / DTS Neural:X
– / o

DTS Virtual:X
o

Dolby TrueHD / Dolby Atmos
o / o

Dolby ProLogic Il / Dolby Surround
– / o

Dolby Height Virtualization
o

Front Wide Speakers: Dolby / DTS
o / o

Auro 3D
13ch

IMAX Enhanced
o

MPEG-H
o

Multichannel Stereo
o

Dialog Enhancer
o

Max Number of Processing (Preamp) Channels
13.4

SOUND ENHANCEMENTS

Mono Block Power Amp Construction
o

Single Board Power Amplifier
o

Discrete Power Amplifier
11

Copper plated transformer base
–

D.D.S.C. HD Digital
o (32 bit)

Copper plated chassis
–

Power Transformer: Toroidal / EI
EI

Current Feedback Topology
–

Hyper Dynamic Amplifier Modules (HDAM)
–

Pure Direct
o

High Grade Audio Components
o

Gold Plated RCA Terminals
o

Clock Jitter Reducer
o

Alpha Processing
AL32 Processing Multichannel

Audyssey
MultEQ XT32

Audyssey Dynamic EQ / Dynamic Volume
o / o

Audyssey LFC
o

Audyssey APP support
o

Audyssey MultEQ X compatible
o

Dirac Live Upgradability
o

Speaker Setup Presets
2

Compressed Audio Restorer
o

Compressed audio Enhancer: MDAX2
–

NETWORK

HEOS Multiroom and Streaming
o

Lossy Formats: MP3 / WMA / AAC
o / o / o

Lossless Formats: FLAC / ALAC / WAV
o / o / o

DSD Audio Streaming
up to DSD5.6

FLAC HD 192/24
o

WAV 192/24
o

ALAC 192/24
o

Gapless Playback
o (FLAC, WAV, ALAC, DSD)

AirPlay 2
o

Roon Tested
o

Internet Radio
TuneIn

o / o / o / o

Amazon Prime Music*
o

Compatible with Remote APP for Smart Phones
Android / iOS

Compatible with Remote APP for Tablets
Android / iOS/Amazon Kindle

Ethernet Ports
o

Wi-Fi
o

Bluetooth
o

Bluetooth Headphone transmission
o

Bluetooth Headphone Volume Control
o

HDMI

HDMI Inputs: Back / Front
7 / 0

HDMI Outputs: Main / Zone
2月1日

HDMI max Resolution (8k / 4k)
8k/60 – 4k/120

Video Conversion Analog -> HDMI
o (480i/576i)

HDMI to HDMI Scaling
1080p/4K to 8K

HDMI: 8K / 4K / CEC / eARC
o / o / o / o

HDMI: Dolby Vision / HDR 10+ / Dynamic HDR / HLG
o / o / o / o

HDMI: ALLM / QMS / QFT / VRR
o / – / o / o

HDMI pass-though in standby mode
o

DSD Audio Capability
o

MULTIROOM/CI

HEOS Multiroom integrated
o

TV Sound grouping
o

Multiroom zones
3

Main room multichannel audio – Zone stereo downmix
o

Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog
o (2ch) / o (2ch) / o / o

Zone Audio Output: Speaker / Preout
o / o

Zone HDMI Output from HDMI Source
o

Webbrowser Setup
o

IP Control / RS232 Control / Web Control / App Control
o / o / o / o

Remote In / Out
o / o

IR Flasher In
–

Marantz remote bus
–

DC Trigger Output
3

OTHERS

Voice Control – Works with Amazon Alexa
o

Voice Control – Google Assistant / Apple Siri
o / o

Auto Speaker Setup by Microphone
Audyssey MultEQ XT32

Front Display
2 lines FLD

Graphic User Interface – GUI
High Definition 1080p

GUI Languages
9

Setup Assistant
o

Quick Select Plus / Quick Select
o / –

Smart Select
–

Firmware Update by Network / USB
o / o

Variable Cross Over
o

Optimized Bass Redirection
o

Bass Sync
o

HDMI Diagnostic Mode
o

ECO Mode
o

Auto Power Off
o

Sleep Timer
o

Speaker Terminal: Gold plated screw / regular screw
o / –

Number of Speaker Terminals
13

Speaker A / B
assignable

Bi-amp drive
assignable

Multi-Room Speaker Terminal
assignable

USB Audio Input Front
o

USB Power 5V/1.5A Rear
o

DAB / DAB+ tuner
–

FM Tuner with RDS
–

Tuner: FM / AM
– / –

INPUTS/OUTPUTS

Composite In / Out
2 / 0

Component In / Out
1 / 0

HDMI In / Out
7月3日

Multi-room Video Out: Video / HDMI
– / o

Analogue In / Out
6 / –

Phono (MM) In
o

Digital In: Optical / Coaxial
2月2日

Multi-room Out: Analog / Digital
2 / –

Multichannel Preout
o (13.4)

Subwoofer Out
4 (independent)

Bass Shaker output
o

POWER

Number of Poweramps
11

Power Output (8 ohm, 20 Hz – 20 kHz, 0.08% 2ch Drive)
–

Power Output (8 ohm, 20 Hz – 20 kHz, 0.05% 2ch Drive)
140 W

Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive)
175 W

Power Output (6 ohm, 1 kHz, 1% 1ch Drive)
205 W

Power Output (6 ohm, 1 kHz, 10% 1ch Drive)
250 W

GENERAL

Available Colours: Black

Metal Front Panel
o

System Remote Control
RC-1256

Backlit Remote
–

Power Consumption in W
750

Power Consumption No-Sound (ECO On / Off) in W
65 W / 110 W

Standby Consumption in W
0.1

Available Colours: Gold / Silver / Black / Silver-Gold
–

CEC Standby Consumption in W
0.5

Network Control On Consumption in W
Less than 2.0

Maximum Dimensions
Antenna:Horizontal: (W x D x H) in mm
Antenna:Vertical: (W x D x H) in mm
No Antenna: (W x D x H) in mm
434 x 389 x 167
( 434 x 389 x 237 )
【 434 x 379 x 167 】

Weight in kg
15.6
