NAD T778 AV Amplifier



NAD’s reference Audio Video Receiver (AVR) is a cutting-edge powerhouse for state of the art music and home theater.


CALL 02 9317 3330


Introducing the T 778 A/V Surround Amplifier

BluOS Enabled 4K Ultra HD Receiver with Immersive Sound
NAD’s reference Audio Video Receiver (AVR) is a cutting-edge powerhouse for state of the art music and home theater. Well known for our high value/ high performance reputation in the AVR category, the brand’s reference model builds on that legacy with an expansion of unwavering philosophy of real-world performance, simplicity of operation, and future upgradeability.

Efficient Distortion-free Amplification
The T 778 features the latest developments in NAD’s Hybrid Digital technology to create 9 high current/high power channels of amplification with improved efficiency. Designed with NAD’s full disclosure approach to power ratings, the NAD AVR conservatively delivers 85W FDP and 9 x 140W FTC, all channels driven at rated distortion. For flexibility, the amp channels are configurable to be used for surround or second zone audio. The silent black background and explosive dynamics afforded by this amplifier technology add lifelike realism, drama and excitement to all your music and movies.

Fully Featured Surround
The T 778 is second-to-none in terms of flexibility and up-to-the-minute digital technology. Only NAD offers Modular Design Construction (MDC), the company’s proven method for preventing premature obsolescence. 7.1.4 Dolby® Atmos™, DTS® Master Audio combine with Dirac Live™ room correction to deliver hyper-realism that captures every dimension of a performance. Add bit-perfect 4K UHD video pass-through and the T 778 delivers the most accurate sound and image experience you’ve ever had. Musical performance is outstanding with High Res Multi-room streaming via BluOS.

Complete and Compact
As with all NAD components, the company’s latest offering continues its ‘simple is better’ design philosophy. This sensible approach contributes to ease of use and maximizes performance where it counts. A perfect example is the striking new touch screen and ergonomic refinements that simplify operation and ease of access. The T 778 features NAD’s legendary sound quality along with complete compatibility with all the latest features and formats to ensure lifelike music and movie enjoyment.

Key Features of the NAD T 778:

9 channels of NAD’s latest Hybrid Digital Amplifier Technology
New touch screen and improved ergonomics for user-friendly operation
4K UHD video pass-through
High-Res BluOS enabled Network Streaming
Dirac Live Room Correction
Full decoding of MQA content via BluOS.
Apple AirPlay 2, ROON Ready, Tidal Connect, Spotify Connect
MDC (Modular Design Construction) offers the ability to upgrade to future digital formats as they become available. Two MDC slots are provided.
CI friendly- RS232 Serial Control Port. Trigger In/Out.
*Note: The T 778 will include a license for Dirac Live with the option for advanced users to upgrade to a Pro version. Firmware version 2.12.9 or later is required to enable Dirac Live. For more information on how to upgrade your device’s firmware, click here.



8 Ohms:140W (21.5dBW)
4 Ohms:170W (22.3dBW)
Full Disclosure Power (all channels driven simultaneously at full bandwidth at rated distortion): 9 x 85W
IHF Dynamic Power:8 Ohms 165W (22.2dBW) 4 Ohms 280W (24.5dBW)
Total harmonic distortion at rated power:<0.08% IM distortion at 1/3 rated power:<0.03% Damping factor:>300 (20Hz-1kHz, 8 ohms)
Input sensitivity and impedance: 1.12Vrms (ref. 8 Ohms, VOL at 0dB)
Frequency response: +0.3/-0.8dB (ref. 1kHz, 20Hz-20kHz)
Signal/noise ratio:>100dB (ref. rated power at 8 Ohms, A-Weighted)
Signal/noise ratio: >85dB (ref. 1W at 8 Ohms, A-Weighted)



Frequency response:±0.3dB (ref. 20Hz – 20kHz)
Signal-to-noise ratio:>100dB (ref. 2V, A-Weighted)
Total harmonic distortion:<0.01% Input sensitivity:245mVrms (ref. 2V)
Maximum output level:>4.5Vrms


Input Sensitivity: 6.2mVrms (ref. 2V)(ref. 20Hz – 20kHz)
Signal-to-noise ratio:>80dB (ref. 2V, A-Weighted)
Maximum Input Level:>90mVrms (1kHz)

Power Consumption

Standby power:<0.5W (full standby)<8W (network standby) Dimension and Weight

Unit Dimensions (W x H x D): 435 x 140 x 430mm (Gross)*
**Net Weight: 12.1kg (26.7lb)
Shipping Weight: 15.5kg (34.2lb)

*Gross dimensions include feet, extended buttons and rear panel terminals.

**Non-metric measurements are approximate.
