Denon PMA 900HNE Stereo Integrated Amplifier with HEOS Streaming

Description

Overview
The Denon PMA-900HNE Integrated Network Amplifier, featuring Advanced High Current amplifier design, delivers superior audio from analog and digital sources. With phono input, digital inputs for TV sound, plus network audio streaming by HEOS® Built-in, Denon PMA-900HNE upgrades your listening experience from any source.

Features

Streaming amplifier with analogue and digital connectivity
Advanced High Current integrated amplifier with 85W
Built-in music streaming via Wi-Fi, Bluetooth, and AirPlay 2 capability
Over 110 years of audio innovation
MM and MC phono equalizer
Optical and coaxial digital inputs
High-grade audio components
Hi-Res Audio Certified
TV auto standby (digital input)

ADVANCED HIGH CURRENT INTEGRATED AMPLIFIER WITH 85W
Engineered with premium Denon amplifier technology and Advanced High Current capability, the PMA-900HNE integrated amplifier drives your loudspeakers with 85 watts of power-per-channel into 4 ohms.

BUILT-IN MUSIC STREAMING VIA WI-FI, BLUETOOTH, AND AIRPLAY 2 CAPABILITY
The HEOS® Built-in Wi-Fi connects to your network to provide near-limitless streaming options. Listen to a wide array of online music services or connect to a smart device via AirPlay 2 or Bluetooth.

MM AND MC PHONO EQUALIZER
The PMA-900HNE includes a phono equalizer that supports input from both MM and MC cartridges. The simple, straightforward design significantly improves sound quality.

OPTICAL AND COAXIAL DIGITAL INPUTS
The PMA-900HNE features three optical inputs and one coaxial input and supports PCM signals up to 192 kHz/24-bit to improve sound quality of your TV audio and more.

SPECIFICATIONS

Output power 8 Ohm (20 Hz – 20 kHz, T.H.D. 0.07%)
50W + 50W

Pre Amplifier Circuit
Variable Gain Preamplifier

Source Direct
o

Signal to Noise Ratio: MM/MC
86 dB / 71 dB

Treble Control
± 8 dB at 10 kHz

Output power 4 Ohm (1 kHz, T.H.D. 0.7%)
85W + 85W

Power Amplifier Circuit
Advanced HC Single Push-Pull Circuit

Volume
Electric – Controlled by Encoder

Input Sensitivity: MM
2.5mV / 47 kohm

Input Sensitivity: High level
105 mV / 40kohms (Source Direct Off)

Bass Control
± 8 dB at 100 Hz

Total Harmonic Distortion
0.01% (-3dB, 8ohm, 1kHz)

Power Amp Output circuit Structure
Single Push-Pull with Darlington transistor

Bass / Treble / Mid / Balance Control
o / o / – / o

Signal to Noise Ratio: High level
105dB

FEATURES

Advanced HC-TR single push pull circuit
o

Power amp discrete construction
o

Wi-Fi / Wired LAN
o / o

Internet radio
o (TuneIn)

Spotify Connect
o

Sound Cloud
o

Napster
o

AWA
o (Japan)

DSD-Audio network streaming
o (5.6Mhz)

Gapless Playback
o

USB-A: DSD / WAV / FLAC / AIFF / ALAC
<=5.6 192=”” 192=”” no=””>

Works with Apple AirPlay (Siri)
o

Wide range amplifier
o

Micro processor auto off
o

Wi-Fi
2.4GHz (11b/g/n)
5GHz (11a/n/ac)

Pandora
o (NA)

Deezer Premium+ / Deezer HiFi
o / – (NA / EU)

Tidal
o (NA / EU)

iHeartRadio
o (NA)

Other
o

Lossy Formats: MP3 / WMA / AAC
o / o / o

Remote APP: iDevice / Android
o / o

Works with Amazon Alexa
o

High current dynamic power supply
o

Solid Heat Sinks
o

Wi-Fi Off Mode
o

Bluetooth / aptX / NFC
o / – / –

Sirius XM Internet Radio
o (NA)

QQ MUSIC
o (China)

Amazon Music Unlimited / Amazon Music HD / Prime Music
o / o / o

Mood Mix
o (NA / EU)

AirPlay
o (Airplay 2)

Lossless Formats: DSD / FLAC HD 192/24 / ALAC 96/24 / WAV 192/24 / AIFF
o / o / o / o / No

DSD-Audio network streaming
o (5.6Mhz)

Sample Rate digital In
192 kHz / 24-bit

Works with Google Assistant
o

AUDIO INPUTS

Digital in: USB-B / optical / coaxial / USB-A
0 / 3 / 1 / 1

Phono Input: MM / MC
o / o

AUDIO OUTPUTS

Pre-out / Main-in
Subwoofer / No

Speaker A / B
o

Headphone Gain Control (low / mid / high)
No

Power Amp Direct IN
No

Remote Control Bus in / out
o (Remote Out)

Gold plated Cinch
o

Headphone Out
o

GENERAL

Available Colours: Black / Premium Silver
o / o

Standby Consumption in W
0.2W

Remote Control
o

Weight in kg
8.3kg

Metal Front Panel
Aluminum

Auto Power Off
o

System Remote Function
o

Carton Maximum Dimensions (W x D x H)
518 x 209 x 385

Power Consumption in W
200W

Detachable Power Cable
o

Maximum Dimensions (W x D x H)
434 x131 x 376

Carton Weight (inc. product) in kg
10.3kg

OTHERS

Low Noise OELD display
o

Ir learning for TV
o

Source Direct
o

Display: Dimmer / Off
o / o
