Description
FEATURES:
- Performance, power and connectivity to suit your listening and entertaining preferences
- 11-channel discrete power amplifier delivers 140W per channel (8-ohm, 20Hz – 20kHz, 0.05% THD, 2ch. drive)
- 4 Independent Subwoofer Outs
- Marantz proprietary Hyper Dynamic Amplifier Modules (HDAM SA-2) amplification circuitry
- Dolby Atmos, DTS: X IMAX Enhanced, and more multi-dimensional surround formats supported
- 8K HDMI inputs and outputs for 8K quality video from the latest Ultra-HD source devices and displays
- 7 HDMI inputs with 8K upscaling and Enhanced Audio Return Channel (eARC) HDMI support
- 3 HDMI outputs for a second monitor plus Zone 2 (4K)
- 8K/60Hz, 4K/120Hz pass-through or upscaling along with HDR10+ and Dynamic HDR
- Supports Dolby Vision, eARC and ALLM for enhanced picture and audio
- SHARC Dual DSP with 32-bit ESS Sabre DAC
- Audyssey MultEQ XT32 Advanced Room Optimisation
- High-Res audio streaming with FLAC, ALAC, and WAV support up to 24-bit/192-kHz, as well as DSD 2.8/5.6MHz
- HEOS Built-in for multi-room streaming, music streaming and voice control
- Built-in Wi-Fi with 2.4GHz/5GHz dual-band support (dual antenna)
- Supports all major voice control agents and streaming services
- Integrated MM phono input to directly connect your turntable
High Power & Low Distortion
Each channel is rated at 140W with 0.05% THD, making both powerful dynamics and subtle detail a reality.
11 Channels & Countless Configurations
Though 11 amplifier channels are built in, CINEMA 30 can process up to 13.4 channels, making the perfect speaker layout for your room easy to achieve.
No Compromise Engineering
Hi-Fi performance technologies like HDAM SA-2, monolithic symmetrical amplifiers, toroidal transformer-based power supplies, and more elevate CINEMA 30 to performance levels seldom found in an AVR.
Sound Master Tuned & Calibrated for You
Premium and custom ingredients are chosen by the Marantz Sound Masters to capture The Most Musical Sound. Powerful calibration and tuning tools are included, enabling you to get the best performance from your system.
Compatibility
7 HDMI inputs, plus digital, analogue, and phono inputs – even analogue video plus loudspeaker and pre-amp outputs – ensure connectivity to virtually any components you have.
Timeless Yet Modern Style
Excellence is heard and seen. CINEMA 30 is meticulously crafted in Japan with authentic materials in a modern style, befitting its rich heritage and stunning performance.
Dirac Live Optional Upgrade
Dirac Live calibration is optionally available as an upgrade and includes Dirac Live Bass Control, allowing for fully optimised low frequency integration for up to four independent subwoofers, giving perfectly coherent bass response in even the most challenging room environment.
A Complete Digital and Analogue Solution
The CINEMA 30 scales to meet an extensive range of system configurations now and in the future. Each of its 7 HDMI inputs can support 8K video and its brand-new high resolution user interface makes setup and customisation seamless. Multiple analogue and digital inputs, coupled to an extensive range of custom installation optimised features means the CINEMA 30 can be adapted to suit all customer use cases, from intimate media rooms, through to large dedicated home theatres.
HEOS Multi-Room Support and Beyond
The CINEMA 30 also supports the latest HEOS whole-home multi-room platform giving effortless access to a broad range of streaming service content, all seamlessly integrated into one unified user experience. Spotify Connect, AirPlay 2™ and Bluetooth complement HEOS to ensure access to the broadest possible range of mobile devices and use cases. Additionally, the CINEMA 30 can be integrated with your choice of Alexa, Google or HomePod Voice Assistant for the ultimate in simple yet smart accessibility.
SPECIFICATIONS
Multichannel Surround
– DTS HD Master / DTS:X / DTS:X Pro / DTS Neo:6 / DTS Neural:X / DTS Virtual:X: Yes / Yes / Yes / No / Yes / Yes
– IMAX Enhanced: Yes
– Dolby TrueHD / Dolby Atmos / Dolby Atmos Height Virtualization: Yes / Yes / Yes
– Dolby Atmos Music / Dolby ProLogic II / Dolby Surround: Yes / No / Yes
– Auro 3D: Yes
– 360 Reality Audio / MPEG H: Yes / Yes
– Multichannel Stereo: Yes
– Max. Number of Processing (Preamp) Channels: 13.4
Sound Enhancements
– Discrete Power Amplifier: Yes
– Copper Plated Chassis: Yes
– Power Transformer: Toroidal
– Current Feedback Topology: Yes
– Hyper Dynamic Amplifier Modules (HDAM): Yes
– Pure Direct: Yes
– Gold Plated RCA Terminals: Yes
– Clock Jitter Reducer: Yes
– Audyssey: MultEQ XT32
– Audyssey Dynamic EQ / Dynamic Volume / Audyssey LFC: Yes / Yes / Yes
– Dirac Live upgradability: Yes
– Compressed Audio Enhancer: MDAX2: Yes
Network
– HEOS Multi-Room and Streaming: Yes
– Bluetooth Re-Transmit for Bluetooth headphones: Yes (with volume control)
– Works with Alexa: Yes
– Network Audio Sharing: Yes
– Lossy Formats: MP3 / WMA / AAC
– Lossless Formats: FLAC / ALAC / WAV
– Lossless formats: FLAC HD 192/24 / WAV 192/24 / ALAC 192/24
– DSD Audio Streaming: Yes, 2.8/5.6 MHz
– Gapless Playback: Yes (FLAC, WAV, ALAC, DSD)
– AirPlay Audio Streaming: Yes (AirPlay 2)
– Internet Radio: Yes (TuneIn)
– Spotify: Yes (Spotify Connect)
– Other Streaming Services: Amazon Music HD / TIDAL / Deezer / Napster / Soundcloud / Mood Mix
– Roon tested: Yes
– Compatible with Remote App for Smart Phones: Marantz AVR Remote
– Compatible with Remote App for Tablets: Android / iOS / Amazon Kindle
– Wi-Fi / Bluetooth / Ethernet Ports: Yes / Yes / Yes
HDMI
– HDCP 2.3 Support: Yes
– HDMI Outputs: Main / Zone: Yes
– Video Conversion Analog → HDMI: Yes
– Analogue to HDMI Scaling: Yes
– HDMI to HDMI Scaling: Yes
– GUI Overlay on HDMI: Yes
– HDMI 2.1: 8K/60Hz AB / 4K/120Hz AB: Yes
– 8K/60Hz AB / 4K/120Hz AB Pass-through In/Out: Yes
– HDMI 2.0: 3D / 4K / CEC / ARC: Yes
– HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR: Yes
– ALLM (Auto Low Latency Mode) Pass-through for Gaming: Yes
– Variable Refresh Rate / Quick Flame Transport / Quick Media Switching: Yes / Yes / No
– 3D Signal Pass-through: Yes
– 8K Signal Pass-through / Scaling / GUI Overlay: Yes / Yes / Yes
– 4K Signal Pass-through / Scaling / GUI Overlay: Yes / Yes / Yes
– HDMI Pass-through in Standby Mode: Yes
– CEC: Yes
– DSD Audio Capability: Yes
– Audio Return Channel: ARC, eARC
– Auto LipSync: Yes
Multiroom / CI
– HEOS Multi-Room Integrated: Yes
– Multi-Room zones: 3
– Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analogue: Yes (2ch) / Yes (2ch) / Yes / Yes
– Zone Audio Output: Speaker / Preout: Yes / Yes
– Zone HDMI Output from HDMI Source: Yes
– IP Control / RS232 Control / Web Control / App Control: Yes / Yes / Yes / Yes
– IR Flasher In: Yes
– Marantz Remote Bus: Yes
– DC Trigger Output: 3
– HDMI Diagnostics: Yes
Inputs/Outputs
Video
– Composite In / Out: 2 / 0
– Component In / Out: 1 / 0
– HDMI In / Out: 7 / 3
– Multi-Room Video Out: Video / HDMI: No / Yes
Audio
– Analogue In / Out: 7 / 0
– Phono (MM) In: Yes
– Digital In: Optical / Coaxial: 2 / 2
– Multi-Room Out: Analogue / Digital: 2 / 0
– Multichannel Pre Out: Yes (13.4)
– Subwoofer Out: 4 (independent)
Other
– Speaker Terminal: Gold Plated Screw / Regular Screw: Yes / No
– Number of Speaker Terminals: 13
– Speaker A / B: Assignable
– Bi-Amp Drive: Assignable
– Multi-Room Speaker Terminal: Assignable
– Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB: No / No / No / No / Yes
– USB Audio: Yes
– USB Power supply on rear panel: Yes
Specifications
– Number of Poweramps: 11
– 8 ohm, 20 Hz – 20 kHz, 0.05% 2ch Drive: 140 W
– 6 ohm, 1 kHz, 0.7% 2ch Drive: 175 W
– 6 ohm, 1 kHz, 10% 1ch Drive: 250 W
– 70% Guarantee: Yes
Others
– Auto Speaker Setup by Microphone: Audyssey MultEQ XT32, Dirac Live (upgrade)
– Front Display: 2 line FLD + port hole OLED
– Graphic User Interface – GUI: Modern HD GUI
– GUI Languages: 9
– Setup Assistant: Yes
– Smart Select: Yes
– Firmware Update by Network / USB: Yes / Yes
– Variable Crossover / Optimized Bass Redirection / Bass Sync: Yes / Yes / Yes
– ECO Mode / Auto Power Off / Sleep Timer: Yes / Yes / Yes
General
– Metal Front Panel: Yes
– System Remote Control: RC051SR
– Pre-Programmed / Learnable / LCD Display: Yes / Yes / Yes
Consumption
– Power: 780 W
– Power, No Sound (ECO on / off): 65 W / 110 W
– Standby: 0.2 W
– CEC Standby: 0.5 W
– Network Standby: Less than 2.0 W
– Network Control, ON: Less than 2.0 W
Maximum Dimensions
– Antenna, Horizontal: (W x D x H) in cm: 442 x 457 x 189
– Antenna, Vertical: (W x D x H) in cm: 442 x 457 x 257
– w/o Antenna: (W x D x H) in cm: 442 x 447 x 189
– Weight in kg: 19.4
What’s in the box
– Main unit
– remote control
– batteries
– wire labels
– quick start guide
– Audyssey microphone
– cardboard microphone stand
– 2 external detachable antennas
– AC cord
