Marantz Cinema 60 7.2 CHANNEL 100 WATTS PER CHANNEL AV RECEIVER With HEOS Streaming



High-performance 7.2 channel AV receiver with 100 watts per channel amplification, Dolby Atmos, DTS:X, 8K Ultra HD, and HEOS Built-In streaming. CINEMA 60 is the new standard of foundational luxury home theatre.


CALL 02 9317 3330


Peerless Performance
Immersive spaciousness, warm and rich tone, and lifelike dynamics are legendary hallmarks of Marantz sound.

Technology Leader
CINEMA 60 comes packed with the latest immersive audio formats, 8K video, room optimization, streaming, and more technology to simplify and elevate your enjoyment.

Exquisite Design
A modern expression of timeless design principles, CINEMA 60 includes our iconic porthole, symmetry, and visual cues representing legendary Marantz quality.

Technical Specifications

Number of Powered Channels: 7
Power Output (8 ohm, 20 Hz – 20 kHz, 0.08% 2ch Drive): 100 W
Power Output (8 ohm, 20 Hz – 20 kHz, 0.05% 2ch Drive):
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive): 140 W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive): 200 W
Discrete Power Amplifier: Yes
Amplifier Topology: Class A/B
Current Feedback Topology: Yes
Bi-Amp Drive: assignable

DTS: DTS HD Master, DTS:X, DTS Neural: X, DTS Virtual:X
Dolby: Dolby TrueHD, Dolby Atmos, Dolby Atmos Height Virtualization, Dolby Atmos Music, Dolby Surround
Max Number of Processing (Preamp) Channels: 7.1

Composite In / Out: 0/0
Component In / Out: 0/0
HDMI In / Out: 6 / 2
Multi-Room Video Out via HDMI: No
Analog In / Fixed Level Out: 4 in / 0 out
Phono (MM) In: Yes
Digital In: Optical / Coaxial: 2 / 2
Multi-Room Out: analog/digital: 1 / 0
Multichannel Preamp Out: 7.2
Subwoofer Out: 2
7.1 multichannel input: No
Number of Speaker Terminals: 7
Speaker A / B: assignable
Multi-Room Speaker Terminal: assignable
Front Inputs: USB-A
USB Audio / Made for iPod / Made for iPhone: Yes / No / No
AM/FM Tuner: Yes

Total HDMI Inputs / No. Support 8K: 6 / 3
HDCP2.3 support: Yes
HDMI Outputs: Main / Zone: 2 / 0
Analog to HDMI Video Conversion: No
HDMI Upscaling: 1080P/4K to 8K
Max resolution @ framerate: 8K/60Hz, 4K/120Hz
Audio Return Channel: ARC, eARC
Video Dynamic Range: HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR
ALLM (Auto Low Latency Mode) Pass-through for gaming: Yes
Variable Refresh Rate / Quick Frame Transport: Yes / Yes
HDMI Pass-Through in Standby Mode: Yes
CEC: Yes
DSD Audio over HDMI: No
Auto LipSync: Yes

Copper Plated Chassis: No
Toroidal Power Supply Transformer: No
Hyper Dynamic Amplifier Modules (HDAM) (List version): Yes
Pure Direct Mode: Yes
Gold Plated RCA Terminals: No
Clock Jitter Reducer: No

Audyssey: MultEQ XT
Audyssey Dynamic EQ / Dynamic Volume: Yes / Yes
Audyssey LFC: No
Dirac Live Support: No
Variable Cross Over: Yes
Optimized Bass Redirection: Yes
Bass Sync: No

Lossy Formats: MP3 / WMA / AAC
Lossless formats: FLAC HD 192/24 / WAV 192/24 / ALAC 192/24
DSD Audio: 2.8 MHz / 5.6MHz
Gapless Playback: FLAC, WAV ,ALAC ,DSD
Compressed Audio Enhancer: MDAX2 Yes
Network Audio Sharing: Yes

HEOS Multi-room and Streaming: Yes
AirPlay Audio Streaming: AirPlay 2
Internet Radio: TuneIn
Spotify*: Spotify Connect
Pandora: Yes
SiriusXM: Yes
Other Streaming Services *: Amazon Music HD/
Amazon Music / TIDAL / Deezer / iHeart Radio / Napster / SoundCloud / Mood Mix
Roon tested: Yes

Ethernet Ports: Yes
Wi-Fi (include version/band): Yes
Bluetooth (Include version): Yes
Bluetooth Re-transmit for Bluetooth headphones: Yes

Voice Assistant Compatibility: Alexa / Google Voice Assistant / Apple HomePod
App for Smart Phones & Tablets: (iOS & Android) Marantz AVR Remote App, HEOS
HEOS Multi-Room Integrated: Yes
HEOS Link Compatibility: IR/ IP: Yes / Yes
Multi-Room zones: 2
Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog 2 Ch / 2Ch / Yes / Yes
Zone Audio Output: Speaker / Preout: Yes / Yes
Zone HDMI Output from HDMI Source: No
Control Connectivity: IP Control / RS232 Control / Web Control / App Control
IR Flasher In: Yes
Marantz Remote Bus: Yes
DC Trigger Output: 1
HDMI Diagnostics: Yes

Front Display: port hole OLED
GUI Languages: 3
Setup Assistant: Yes
Smart Select on Remote: Yes
Firmware Update by Network / USB: Yes / Yes
ECO Mode: Yes
Auto Power off: Yes
Sleep Timer: Yes

Available colours: Black
Metal Front Panel: No
System Remote Control: RC049SR
Power Consumption in W: 650
Power Consumption No-Sound (ECO on/off) in W: 45/ 75
Standby Consumption in W: 0.2
CEC Standby Consumption in W: 0.5
Network Standby Consumption in W: Less than 2.0

Antenna:Horizontal:(W x D x H) in mm: 442 x 354 x 165
Antenna:Vertical :(W x D x H) in mm: 442 x 354 x 235
W/o Antenna:(W x D x H) in mm: 442 x 343 x 165
Weight in kg: 10.9
What’s in the box: Main unit, remote control, batteries, AM/FM antennas, wire labels, quick start guide, Audyssey microphone, cardboard microphone stand, 2 External Detachable Antenna, AC cord
