Description
Peerless Performance
Immersive spaciousness, warm and rich tone and lifelike dynamics are legendary hallmarks of Marantz sound.
Technology Leader
CINEMA 50 abounds with the latest immersive audio formats, 8K video, room optimization, streaming, and more technology to simplify and elevate your enjoyment.
Exquisite Design
A modern expression of timeless design principles, CINEMA 50 features the iconic Marantz porthole, symmetrical design, and front panel controls elegantly hidden from view.
Effortless
Included remote, accessible front-panel controls, and an intuitive on-screen setup process makes you feel like an expert user right away.
Compatibility
Seven HDMI inputs, plus digital, analogue and phono inputs plus loudspeaker and pre-amp outputs ensure connectivity to virtually any other components you may have.
Upgradeability
Extensive input and output options plus a powerful software ecosystem make CINEMA 40 easy to upgrade as your home theatre grows.
Style
Excellence is heard and seen. CINEMA 50 features architectural design that can be featured or remain discreet in any luxurious environment.
Customizability
Thoughtfully selected connectivity options, flexible speaker arrangements, and fine-tuning ability allow you to make CINEMA 50 your own.
Effortless
Included remote, accessible front-panel controls, and an intuitive on-screen setup process make you feel like an expert user right away.
Compatibility
Seven HDMI inputs, plus digital, analogue and phono inputs plus loudspeaker and pre-amp outputs ensure connectivity to virtually any other components you may have.
Upgradeability
Extensive input and output options plus a powerful software ecosystem make CINEMA 40 easy to upgrade as your home theatre grows.
Technical Specifications
POWER AMPLIFIER
Number of Powered Channels: 9
Power Output (8 ohms, 20 Hz – 20 kHz, 0.08% 2ch Drive); 110 W
Power Output (8 ohms, 20 Hz – 20 kHz, 0.05% 2ch Drive): –
Power Output (6 ohms, 1 kHz, 0.7% 2ch Drive): 150 W
Power Output (6 ohms, 1 kHz, 10% 1ch Drive): 220 W
70% Guarantee: Yes
Discrete Power Amplifier: Yes
Amplifier Topology: Class A/B
Current Feedback Topology: Yes
Bi-Amp Drive: assignable
MULTICHANNEL SURROUND TECHNOLOGIES
DTS: DTS HD Master, DTS:X, DTS Neural:X, DTS Virtual:X
Dolby: Dolby TrueHD, Dolby Atmos, Dolby Atmos Height Virtualization, Dolby Atmos Music, Dolby Surround
Other: IMAX Enhanced, Auro-3D, 360 Reality Audio, MPEG H, Multichannel Stereo
Max Number of Processing (Preamp) Channels: 11.4
INPUTS/OUTPUTS
Composite In / Out: 0/0
Component In / Out: 0/0
HDMI In / Out: 6 / 3
Multi-Room Video Out via HDMI: Yes
Analog In / Fixed Level Out: 5 in / 0 out
Phono (MM) In: Yes
Digital In: Optical / Coaxial: 2 / 2
Multi-Room Out: analog / digital: 1 /0
Multichannel Preamp Out: 11.4
Subwoofer Out: 4 (independent)
7.1 multichannel input: No
Number of Speaker Terminals: 11
Speaker A / B: assignable
Multi-Room Speaker Terminal: assignable
Front Inputs: USB-A
USB Audio / Made for iPod / Made for iPhone: Yes / No / No
AM/FM Tuner: No
USB Audio: Yes
HDMI
Total HDMI Inputs / No. Support 8K: 6 / 6
HDCP2.3 support: Yes
HDMI Outputs: Main / Zone: 2 / 1
Analog to HDMI Video Conversion: No
HDMI Upscaling: 1080P/4K to 8K
Max resolution @ framerate: 8K/60Hz, 4K/120Hz
Audio Return Channel: ARC, eARC
Video Dynamic Range: HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR
ALLM (Auto Low Latency Mode) Pass-through for gaming: Yes
Variable Refresh Rate / Quick Frame Transport: Yes / Yes
HDMI Pass-Through in Standby Mode: Yes
CEC: Yes
DSD Audio over HDMI: Yes
Auto LipSync: Yes
PERFORMANCE TECHNOLOGIES
Copper Plated Chassis: No
Toroidal Power Supply Transformer: No
Hyper Dynamic Amplifier Modules (HDAM) (List version): Yes
Pure Direct Mode: Yes
Gold Plated RCA Terminals: Yes
Clock Jitter Reducer: Yes
ACOUSTIC/ROOM CORRECTION
Audyssey: MultEQ XT32
Audyssey Dynamic EQ / Dynamic Volume: Yes / Yes
Audyssey LFC: Yes / Yes
Dirac Live Upgradability: Yes
Variable Cross Over: Yes
Optimized Bass Redirection: Yes
Bass Sync: Yes
MUSIC FILE SUPPORT
Lossy Formats: MP3 / WMA / AAC
Lossless formats: FLAC HD 192/24 / WAV 192/24 / ALAC 192/31
DSD Audio: 2.8 MHz / 5.6MHz
Gapless Playback: FLAC, WAV ,ALAC ,DSD
Compressed Audio Enhancer: MDAX2: Yes
Network Audio Sharing: Yes
STREAMING SERVICES
HEOS Multi-room and Streaming: Yes
AirPlay Audio Streaming: AirPlay 2
Internet Radio: TuneIn
Spotify*: Spotify Connect
Pandora: Yes
SiriusXM: Yes
Other Streaming Services *: Amazon Music HD/
Amazon Music / TIDAL / Deezer / iHeart Radio / Napster / SoundCloud / Mood Mix
Roon tested: Yes
NETWORK CONNECTIVITY
Ethernet Ports: Yes
Wi-Fi (include version/band): Yes
Bluetooth (Include version): Yes
Bluetooth Re-transmit for Bluetooth headphones: Yes
SMART HOME INTEGRATION AND CONTROL
Voice Assistant Compatibility: Alexa / Google Voice Assistant / Apple HomePod
App for Smart Phones & Tablets (iOS & Android): Marantz AVR Remote App, HEOS
HEOS Multi-Room Integrated: Yes
HEOS Link Compatibility: IR/ IP: Yes / Yes
Multi-Room zones: 2
Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog: 2 Ch / 2 Ch / Yes / Yes
Zone Audio Output: Speaker / Preout: Yes / Yes
Zone HDMI Output from HDMI Source: Yes
Control Connectivity: IP Control / RS232 Control / Web Control / App Control
IR Flasher In: Yes
Marantz Remote Bus: Yes
DC Trigger Output: 1
HDMI Diagnostics: Yes
OTHERS
Front Display: port hole OLED
GUI Languages: 3
Setup Assistant: Yes
Smart Select on Remote: Yes
Firmware Update by Network / USB: Yes / Yes
ECO Mode: Yes
Auto Power off: Yes
Sleep Timer: Yes
GENERAL
Available colours: Black
Metal Front Panel: Yes
System Remote Control: RC049SR
Power Consumption in W: 680
Power Consumption No-Sound (ECO on/off) in W: 60 / 100
Standby Consumption in W: 0.2
CEC Standby Consumption in W: 0.5
Network Standby Consumption in W: Less than 2.0
Maximum Dimensions:
Antenna:Horizontal:(W x D x H) in mm: 442 x 404 x 165
Antenna:Vertical :(W x D x H) in mm: 442 x 404 x 235
W/o Antenna:(W x D x H) in mm: 442 x 392 x 165
Weight in kg: 13.5
What’s in the box: Main unit, remote control, batteries, wire labels, quick start guide, Audyssey microphone, microphone stand, 2 External Detachable Antenna, AC cord
