Description
Style
Excellence is heard and seen. CINEMA 70s slimline design is less than half the height of many receivers, but the design remains luxurious with every element carefully considered.
Customizability
Thoughtfully selected connectivity options and fine-tuning ability allow you to make CINEMA 70s your own.
Effortless
Included remote, accessible front-panel controls, and an intuitive on-screen setup process that makes you feel like an expert user immediately.
Compatibility
Six HDMI inputs, digital, analog and phono inputs plus loudspeaker and preamp outputs ensure connectivity to virtually any other components you may have.
Upgradeability
Extensive input and output options plus a powerful software ecosystem make CINEMA 70s easy to upgrade as your home theater grows.
SPECIFICATIONS
POWER AMPLIFIER
Number of Powered Channels: 7
Power Output (8 ohm, 20 Hz – 20 kHz, 0.08% 2ch Drive): 50 W
Power Output (8 ohm, 20 Hz – 20 kHz, 0.05% 2ch Drive): –
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive): 70 W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive): 100 W
70% Guarantee: Yes
Discrete Power Amplifier: Yes
Amplifier Topology: Class A/B
Current Feedback Topology: No
Bi-Amp Drive: assignable
MULTICHANNEL SURROUND TECHNOLOGIES
DTS: DTS HD Master, DTS:X, DTS Neural:X, DTS Virtual:X
Dolby: Dolby TrueHD, Dolby Atmos, Dolby Atmos Height Virtualization, Dolby Atmos Music, Dolby Surround
Max Number of Processing (Preamp) Channels: 7.2
INPUTS/OUTPUTS
Composite In / Out: 0 / 0
Component In / Out: 0 / 0
HDMI In / Out: 6 / 1
Multi-Room Video Out via HDMI: 0 / 0
Analog In / Fixed Level Out: 3 in / 0 out
Phono (MM) In: Yes
Digital in: optical/coaxial: 1 / 1
Multi-Room Out: analog/digital: 1 / 0
Multichannel Preamp Out: 7.2
Subwoofer Out: 2
7.1 multichannel input: No
Number of speaker terminals: 7
Speaker A / B: assignable
Multi-Room Speaker Terminal: assignable
Front Inputs: USB-A
USB Audio: Yes / No / No
FM Tuner with RDS: Yes
DAB+ Tuner: No
HDMI
Total HDMI Inputs / No. Support 8K: 6 / 3
HDCP2.3 support: Yes
HDMI outputs main / zone: 1 / 0
Analog to HDMI Video Conversion: No
HDMI Upscaling: 1080P/4K to 8K
Audio Return Channel: eARC
Video Dynamic Range: HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR
ALLM (Auto Low Latency Mode) Pass-through for gaming: Yes
Variable Refresh Rate / Quick Frame Transport: Yes / Yes / No
HDMI Pass-Through in Standby Mode: Yes
CEC: Yes
DSD Audio over HDMI: No
Auto LipSync: Yes
PERFORMANCE TECHNOLOGIES
Copper Plated Chassis: No
Toroidal Power Supply Transformer: No
Hyper Dynamic Amplifier Modules (HDAM) (List version): No
Pure Direct Mode: Yes
Gold Plated RCA Terminals: No
Clock Jitter Reducer: No
ACOUSTIC/ROOM CORRECTION
Audyssey: MultEQ
Audyssey Dynamic EQ / Dynamic Volume: Yes / Yes
Audyssey LFC: No
Dirac Live Support: No
Variable Cross Over: Yes
Optimized Bass Redirection: Yes
Bass Sync: No
MUSIC FILE SUPPORT
Lossy Formats: MP3 / WMA / AAC
Lossless formats: FLAC HD 192/24 / WAV 192/24 / ALAC 192/31
DSD Audio: 2.8 MHz / 5.6 MHz
Gapless Playback: FLAC, WAV ,ALAC ,DSD
Compressed Audio Enhancer: MDAX2: Yes
Network Audio Sharing: Yes
STREAMING SERVICES
HEOS Multi-room and Streaming: Yes
AirPlay Audio Streaming: AirPlay2
Internet Radio: TuneIn
Spotify*: Spotify Connect
Pandora: Yes
SiriusXM: Yes
Other Streaming Services *: Amazon Music HD/
Amazon Music / TIDAL / Deezer / Napster / Soundcloud / Mood Mix
Roon tested: Yes
NETWORK CONNECTIVITY
Ethernet Ports: Yes
Wi-Fi (include version/band): Yes
Bluetooth (Include version): Yes
Bluetooth Re-transmit for Bluetooth headphones: Yes
SMART HOME INTEGRATION AND CONTROL
Voice Assistant Compatibility: Alexa / Google Voice Assistant / Apple HomePod
App for Smart Phones & Tablets (iOS & Android): Marantz AVR App
HEOS Multi-Room Integrated: Yes
HEOS Link Compatibility: IR/ IP: Yes /Yes
Multi-Room zones: 2
Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog: 2 Ch / 2 Ch / Yes / Yes
Zone Audio Output: Speaker / Preout: Yes / Yes
Zone HDMI Output from HDMI Source: No
Control Connectivity: IP Control / Web Control / App Control
IR Flasher In: Yes
Marantz Remote Bus: Yes
DC Trigger Output: 1
HDMI Diagnostics: Yes
OTHERS
Front Display: port hole OLED
GUI languages: 9
Setup Assistant: Yes
Smart Select on Remote: Yes
Firmware Update by Network / USB: Yes / Yes
ECO Mode: Yes
Auto Power off: Yes
Sleep Timer: Yes
GENERAL
Metal Front Panel: No
System Remote Control: RC-050SR
Power Consumption in W: 250
Power consumption No-Sound (ECO on / off) in W: 30 W / 40 W
Standby Consumption in W: 0.2
CEC Standby Consumption in W: 0.5
Network Standby Consumption in W: Less than 2.0
MAXIMUM DIMENSIONS
Antenna:Horizontal:(W x D x H) in mm: 442 x 384 x 109
( Antenna:Vertical :(W x D x H) in mm): 442 x 384 x 178
w/o Antenna :(W x D x H) in mm: 442 x 372 x 109
Weight in kg: 8.7
What’s in the Box: Main unit, remote control, batteries, AM/FM antennas, wire labels, quick start guide, Audyssey microphone, card board microphone stand, 2 External Detachable Antenna, AC cord
