Description
Pure Silver
Coil System
All MC X cartridges feature coils wound with high-purity silver wire. The use of premium materials is to ensure exceptional signal clarity, delivering sound with unmatched precision and preserving every detail without interference.
Magnet system
The MC X Series introduces a newly developed magnet system with a one-piece pole cylinder integrated into a rear magnet yoke. Engineered for maximum magnetic efficiency and paired with pure silver coils, this configuration ensures a clean, powerful signal path that elevates overall performance.
Custom-Developed Rubber Dampers
In-house produced and developed rubber compounds form the core of the MC X Series’ mechanical damping system. Rubber dampers are essential for controlling the physical movement of the coils, maintaining stability, minimizing unwanted vibrations, and enabling precise coil motion. The result is superior tracking, reduced distortion, and musical accuracy.
Experience the depth.
Hear every detail.
At the core of the MC X Series is an advanced honeycomb-structured stainless-steel frame, created using Metal Injection Molding (MIM) technology. This refined construction ensures superior mechanical stability, providing an ideal foundation for precise and accurate sound reproduction.
After molding and sintering, a Physical Vapor Deposition (PVD) surface treatment is applied to enhance surface appearance and maintain material integrity over time.
SPECIFICATIONS
Channel balance at 1 kHz
0.5 dB
Output voltage at 1 kHz, 5cm/sec
0.4 mV
Channel separation at 1 kHz
26 dB
Frequency response 20 Hz – 20 kHz
+/-1 dB
Compliance, dynamic, lateral
15 μm/mN
Cantilever material
Aluminium
Stylus type
Nude Fine-Line
Stylus tip radius
r/R 8/40 μm
Stylus suspensions
Ortofon exclusive
Coil system
Quad coils
Tracking force, recommended
2.0 grams
Internal impedance, DC resistance
6 Ω
Coil wire material
High-purity silver
Cartridge weight
8.6 grams
Recommended load resistance
> 50 Ω
