Description
Dolby Atmos
Feel every dimension in Dolby Atmos. Upgrade your home theater with height speakers to unleash a fully immersive 3D audio experience from Dolby Atmos content. Dolby Surround upmixer engages all speakers to create 3D audio sensation from legacy content. Dolby Atmos Height Virtualization Technology creates the sensation of overhead sound even without height speakers. You can also enjoy Dolby Atmos music tracks from Apple Music, Amazon HD, and TIDAL and a compatible streaming device.
DTS:X
DTS:X immersive audio content places sound where it would naturally occur in space, creating lifelike, multidimensional audio. DTS Neural:X upmixer offers improved immersion and heightened realism for legacy content. DTS Virtual:X provides immersive audio without height channels, creating virtual height effects in a 7.1, 5.1, or 2.1 speaker setup.
HDMI Connectivity with ARC/eARC
Supports the latest technology on all HDMI inputs and output. ARC (Audio Return Channel) or eARC (Enhanced Audio Return Channel) makes playing TV audio through your AV receiver simple, with just a single HDMI connection. eARC provides HD and 3D audio transmission such as Dolby TrueHD, DTS HD Master Audio, and Dolby Atmos while ARC is limited to conventional 5.1ch audio formats or PCM.
8K / HDCP 2.3
Enjoy pristine 8K picture quality on your 8K TV or projector. Supports both 8K pass-through and 8K upscaling of 4K content. Supports HDCP 2.3, the latest copy protection standard, for peace of mind when streaming copy-protected content.
Brilliant color from HDR 10+
Supports HDR (High Dynamic Range), HLG (Hybrid Log Gamma), as well as Dynamic HDR and HDR10+ pass-through. HLG offers HDR technology over broadcast content. Both Dynamic HDR and HDR10+ use dynamic metadata to optimize shadows and highlights as screens change.
Dolby Vision
Dolby Vision is a stunning HDR imaging technology that brings extraordinary color, contrast, and brightness to the screen. Compatible with Dolby Vision so you can enjoy Dolby Vision content from a compatible source device and TV.
Next-generation gaming
Supports Variable Refresh Rate (VRR), Quick Frame Transport (QFT), and Auto Low Latency Mode (ALLM) for a smooth, lag-free gaming experience when connected with compatible gaming devices.
HEOS Built-in
With HEOS® Built-in, your AV receiver can stream music wirelessly across compatible HEOS components from a variety of free and premium streaming services. Consumers can also enjoy their favorite music in any room of the home wirelessly. Play the same song in every room or select a different song for each connected room via a variety of streaming sources. Add Denon Home speakers to more rooms and control it all with the HEOS app.
Airplay 2 and Apple Siri Voice Control
Use AirPlay 2 to stream Apple music wirelessly to the AV receiver, or group with other AirPlay compatible speakers to fill your home with music.
Works with Amazon Alexa
Control your AV receiver hands-free with Amazon Alexa and your voice. Adjust the volume, skip to the next track, switch inputs for your different media players, and more—“Just Ask.” Download the free HEOS Home Entertainment Skill to enable Amazon Alexa voice commands. Requires Alexa app and Amazon Echo, Dot, or equivalent.
High-resolution audio via USB input
Discover the incredible fidelity of high-resolution audio tracks and enjoy music as the artist intended. A front USB port supports up to 24bit/192kHz high-res audio playback from a USB drive. Supported audio formats are MP3, WMA, WAV, MPEG-4/AAC, FLAC, and ALAC.
Bluetooth audio transmitter
Pair your favorite Bluetooth headphones with your AV receiver to continue listening to your favorite music, movies, or TV programs at night. You can also play audio from both speakers and Bluetooth headphones simultaneously. If you have a family member or a friend who is hearing impaired, we recommend this setup. You can connect one pair of headphones at a time.
Multi-source, multi-room
By connecting a pair of speakers in a second room to the AV receiver, it’s possible to enjoy 5.1 channel surround sound in the main room and a separate source or music stream in the second room, such as a den or patio. You can also play the same audio in both so that everyone in your home can enjoy and cheer your favorite team on Sunday evening or listen to the same song in both rooms. The AV receiver supports 2-source, 2-zone audio.
Denon Setup Assistant
Award-winning guide Denon Setup Assistant supplies simple, clear instructions to get started. Just connect your AV receiver to your TV and follow the instructions on the TV screen to connect your speakers, perform speaker measurements, and connect source devices. For additional convenience, the AV receiver renames HDMI inputs automatically when connected or you can rename them manually at your convenience.
Audyssey Suites of Room Correction Technology
Denon AV receivers use the Audyssey suite of EQ software for simple, accurate setup and calibration. With the supplied Audyssey measuring microphone, Audyssey measures all the speakers in your home theater and tunes the AV receiver to provide the smoothest, most optimal overall listening experience for your room. This AV receiver supports Audyssey MultEQ room correction technology. The other supported Audyssey features are Dynamic EQ and Dynamic Volume.
Audyssey MultEQ Editor app
You can go even further with the Audyssey MultEQ Editor app, going “under the hood” to view and adjust settings for detailed tuning—allowing you to customize the sound more precisely to the specific problems in your room and tailor the sound to your personal preferences. With this comprehensive app, you can harness the power of Audyssey MultEQ to take total control of the way your home cinema sounds. The app is available for purchase in iOS and Google Play stores.
Denon AVR Remote app
This iOS or Android control app allows you to turn the receiver on and off, select an input source, adjust the volume level, and browse music from your phone or in a USB drive when connected to the receiver.
Works with Google Assistant
Start music in the HEOS app, then ask your Google Assistant to control volume, play, pause, skip tracks, mute, and unmute.
MULTICHANNEL SURROUND
DTS HD Master, DTS:X, DTS:X Pro: Yes, Yes, No
DTS Neo:X, DTS Neural:X: No, Yes
DTS Virtual:X: Yes
Dolby TrueHD, Dolby Atmos, Dolby Atmos Height Virtualization, Dolby Atmos Music: Yes, Yes, Yes, Yes
Dolby ProLogic Ilz, Dolby Surround: No, Yes
Multichannel Stereo: Yes
Max. Number of Processing (Pre-Amp) Channels: 7.1
SOUND ENHANCEMENTS
Discrete Power Amplifier: Yes
Pure Direct: Yes
Audyssey: MultEQ XT
Audyssey Dynamic EQ, Dynamic Volume: Yes, Yes
Compressed Audio Restorer: Yes
NETWORK
Media Server: Yes
HEOS Wireless Multi-Room Technology: Yes
Alexa / Google Voice Assistant / Apple HomePod: Yes, Yes, Yes
Lossy Formats: MP3, WMA, AAC: Yes, Yes, Yes
Lossless Formats: FLAC, ALAC, WAV: Yes, Yes, Yes
Lossless Formats: FLAC HD, WAV, ALAC (all 192kHz/24 bit): Yes, Yes, Yes
DSD Audio Streaming: Yes (2.8/5.6MHz)
AirPlay 2: Yes
TuneIn: Yes
Spotify Connect: Yes
Roon Tested: Yes
HEOS App Control: Yes
Compatible with Remote APP for Smart Phones: Denon 2016 AVR Remote
Ethernet Ports: Yes
Wi-Fi: Yes
Bluetooth: Yes
HDMI
HDMI Inputs: Back, Front: 6, No
HDCP2.3 support: Yes
HDMI Outputs: Main, Zone: 2, No
HDMI 2.1: 8K/60Hz AB, 4K/120Hz AB: Yes, Yes
HDR, HLG, Dolby Vision, HDR10+, Dynamic HDR: Yes, Yes, Yes, Yes, Yes
ALLM (Auto Low Latency Mode) Pass-through for gaming: Yes
Variable Refresh Rate, Quick Frame Transport, Quick Media Switching: Yes, Yes, No
3D Signal Pass-through: Yes
8K Signal Pass-Through, Scaling, GUI Overlay: Yes, Yes, Yes
Audio Return Channel (ARC), Enhanced ARC: Yes, Yes
Auto LipSync: Yes
MULTI-ROOM CI
Multi-Room Zones: 2
Zone Audio Source: HDMI; Optical, Coax, Network, USB; Analog: Yes (2ch), Yes (2ch), Yes, Yes
Zone Audio Output: Speaker, Pre-Out: Yes, Yes
IP Control, RS232 Control, Web Control, App Control: Yes, Yes /Yes, Yes
Remote In / Out: Yes, Yes
HDMI Diagnostics: Yes
OTHERS
Auto Speaker Setup by Microphone: Audyssey MultEQ XT
Front Display: 1-Line FLD
GUI Languages: 3
Setup Assistant: Yes
Quick Select Plus, Quick Select: Yes, No
Variable Crossover: Yes
Optimized Bass Redirection: Yes
ECO Mode: Yes
Auto Power Off: Yes
Sleep Timer: Yes
INPUTS/OUTPUTS
HDMI In, Out: 6, 2
Multi-Room Video Out: Video, HDMI: No, No
Analog In, Out: 4 / No
Phono (MM) In: Yes
Digital In: Optical, Coaxial: 2 / 0
Multi-Room Out: Analog, Digital: 1 / No
Multichannel Preout: Yes (0.2)
Subwoofer Out: 2
Speaker Terminal: Gold-Plated Screw, Regular Screw: No, Yes
Number of Speaker Terminals: 7
Speaker A / B: Assignable
Bi-amp Drive: Assignable
Multi-Room Speaker Terminal: Assignable
Front Inputs: Audio, Composite, Digital (Opt), HDMI, USB: No, No, No, No, Yes
USB Audio, Made for iPod, Made for iPhone: Yes, No, No
AM/FM Tuner: Yes
SPECIFICATIONS
Number of Power Amps: 7
Power Output (8 ohm, 20 Hz – 20 kHz, 0.08% 2ch Drive): 95W
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive): 125W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive): 150W
GENERAL
System Remote Control: RC-1253
Pre-Programmed, Learnable, LCD Display: No, No, No
Power Consumption in W: 500
Power Consumption No-Sound (ECO On / Off) in W: 35W/75W
Standby Consumption in W: 0.1
CEC Standby Consumption in W: 0.5
Network Standby Consumption in W: Less than 2.0
MAXIMUM DIMENSIONS
Antenna:Horizontal:(W x D x H) in mm: 434 x 341 x 167
Antenna:Vertical :(W x D x H) in mm: 434 x 341 x 237
w/o Antenna :(W x D x H) in mm: 434 x 330 x 167
Weight in kg: 9.5
Carton Weight (inc. product) in kg: 11.5
