Denon DP-3000NE Premium Direct Drive Turntable

Description

Direct-drive motor system
Follows a long Denon tradition of direct-drive motor system, with rotation speed that does not fluctuate no matter the selected speed or load. Simple to use, low maintenance, and reaches full speed almost instantly. Denon released its first direct-drive turntable, the DN-302F, for broadcast studios in 1970.

Denon original static balance S-Shape tonearm
Features a carefully engineered S-Shape curved tonearm with optimized tracking angle at any point of the record. This newly improved Denon® arm features cartridge weight adjustment, anti-skating adjustment (0-3 g) and a newly developed arm height adjustment (0-9 mm). It gives you full flexibility to customize your turntable to your preferred cartridges or custom mat.

Space vector PWM motor control
Space vector pulse width modulation (SV-PWM) is a new design for the motor spinning control. SV-PWM is simply an algorithm used to control the PWM (pulse width modulation) module, which basically powers the motor. SV-PWM greatly reduces harmonics in the motor which can cause overheating and torque fluctuations and offers a continuous reliable voltage and frequency output for long periods of listening at any rotation speed or load via continuous feedback of the rotation speed.

SMPS power supply
Switch mode power supply (SMPS) greatly benefits turntables by avoiding the use of a linear transformer, avoiding unnecessary vibrations. It allows integration of the power supply into the turntable, getting rid of any external power transformer or power bricks dangling behind the product. It also avoids voltage and frequency fluctuations from variation in the power grid.

Adjustable insulator feet
The feet are key to protect the playback from any vibration picked up from the surface the turntable is placed on. But these feet are also adjustable to bring the platter perfectly in balance for the most accurate tracking of the needle in the groove.

SPECIFICATIONS

Drive System
Direct

Motor
16-pole, 12-coil, brushless motor

Control method
PWM Vector

Platter
Aluminium diecast (305mm)

Platter inertia
382 kg/cm2

Wow Flatter
less than 0.06% JIS

Speed tolerance
less than ± 0.3%

Rumble (S/N ratio)
Over 70dB

Bearing Type
Miniature Steel
ball bearing

Tone Arm
Static Balanced S-Shaped

Arm length
244mm

Overhang
14mm

Offset angle
20.5°

Tracking error angle
2.5° (Max.)

Suitable cartridge weight
Without sub weight: 4–16g
With sub weight: 14–26g

Stylus force adjustment
0–2.5g / rotation

High adjustment range
9mm

Anti-skating adjustment
0-3g

Headshell material
Aluminium

Speed tolerance
less than ± 0.3%

Sensitivity
Horizontal: 30mg
Vertical: 30mg

Operation
Manual

Speed
33 ⅓ / 45 / 78 rpm

Control
Start / Stop

Colours
Dark Ebony

Dimensions
500 × 394 × 185mm
(W × D × H)

Weight
18.5kg

Power Supply
AC 100-240V, 50/60Hz

Power consumption
< 4W
Standby Power Consumption
Less than 0.3W

Carton maximum dimensions
615 × 515 × 335 mm
(W × D × H)

Carton weight
24.0 kg

What’s in the box:
Platter mat, Dust cover, Power cable, RCA cable
and ground cable, Headshell, Overhang gauge,
Screw set for cartridge mount (10, 13, 18 mm),
2 × Cartridge spacers (1 mm), 2 × Plastic
Washer, Screw driver, Counter weight,
Sub-counter weight, Denon EP adapter/weight
